9 Getting Started
WLA-AWCG User Manual

Connecting to a hub

Connect the other end of the straight-through cable to your hub.

Note:

A straight-through cable can be used to connect to the hub provided the
hub is fitted with a cascade port

Figure 2: AirStation Pro installation setup

4 Connect the power supply

to the DC connector

on the WLA-AWCG.

1 Remove the rear cover

by gently squeezing

both sides, and

then pulling the

cover towards

you.

2 Connect the UTP

straight-through

cable (supplied)

to the LAN port

of the

AirStation.

3 Connect the other end of

the UTP cable to the hub.

WLA-AWCG

100 Base-TX/

10 Base-T-compatible hub
