SECTION 2 - TURNTABLE
3121243 450A Series II/450AJ Series II 81
FIGURE 2-1. CONTROL VALVE INSTALLATION
ITEM PART NUMBER QTY DESCRIPTION REV
9 2120209 1 Belgium Built Machines (SN 1300001242 through
1300006000)
Ref VALVES INSTALLATIONS
Ref 450A Series II
0271124 Ref USA Built Machines (Prior to SN 0300087631) F
0271124 Ref Belgium Built Machines (Prior to SN 1300001242) F
0274615 Ref USA Built Machines (SN 0300087631 through 0300124000) A
0274615 Ref Belgium Built Machines (SN 1300001242 through
1300006000) A
Ref 450AJ Series II
0271197 Ref USA Built Machines (Prior to SN 0300087631) F
0271197 Ref Belgium Built Machines (Prior to SN 1300001242) F
0274616 Ref USA Built Machines (SN 0300087631 through 0300124000) A
0274616 Ref Belgium Built Machines (SN 1300001242 through
1300006000) A
1 0100011 AR Compound, Locking
2 0140001 1 Horn
4 0641404 1 Bolt 1/4in-20NC x 1/2in
5 0651405 4 Bolt 1/4in-24NF x 5/8in
7 0641607 4 Bolt 3/8in-16NC x 7/8in
9 Ref Pressure Filter Assembly Options:
9 2120163 1 Filter for USA Built Machines (Prior to SN 0300087631)
9 2120163 1 Belgium Built Machines (Prior to SN 1300001242)
9 2120150 1 Element, Filter
9 7020020 1 Indicator
9 7023206 1 O-Ring, Filter
9 7023207 1 Ring, Back-up
9 2120209 1 Filter for USA Built Machines (SN 0300087631 through
0300124000)
9 2120210 1 Element, Filter
9 7020020 1 Indicator
9 70000934 1 O-Ring, Filter Bowl
11 4641176 1 Main Control Valve Assembly (See MAIN CONTROL VALVE
ASSEMBLY for Breakdown)
14 4711600 10 Flatwasher 3/8in Thin
15 4751400 1 Flatwasher 1/4in Regular
20 4711400 4 Flatwasher 1/4in Thin
21 4791400 1 Starwasher 1/4in
