SECTION 2 - TURNTABLE
3121243
450A Series II/450AJ Series II
241
ITEM
PART NUMBER
QTY
DESCRIPTION
REV
Ref
(Note: Item 32 must be ordered separately)
50
1001091124
1
Deutz Engine Machines (Includes items 12, 23, 24, 32 and
Current Heat Shields)
50
1001097968
1
Ford Engine Machines (Includes Items 12 and Current Heat
Shields) (Note: Item 32 must be ordered separately)
50
1001091094
1
GM Engine Machines (Includes items 12, 23, 24, 32 & Current
Heat Shields)
51
1001091125
1
Hood Kit (Tank Side) (Includes items 13, 23, 24, 38 & 201-208)
Ref
Note: Replacement Decals Must be Ordered Separately -
See DECAL SECTION.
Ref
HOOD ASSEMBLY OPTIONS (ENGINE SIDE):
101
2940109
1
Latch
102
0721008
2
Screw, Machine #10-24NC x 1in
103
4751000
4
Flatwasher #10 Regular
104
3311005
2
Locknut #10-24NC
105
2600210
1
Hinge
106
3900232
4
Screw, Button Head 3/8in-16NC x 1-1/4in
107
4751600
8
Flatwasher 3/8in Regular
108
3311605
4
Locknut 3/8in-16NC
Ref
HOOD ASSEMBLY (TANK SIDE)
M
201
2940109
1
Latch
202
0721008
2
Screw, Machine #10-24NC x 1in
203
4751000
4
Flatwasher #10 Regular
204
3311005
2
Locknut #10-24NC
205
2600246
2
Hinge
206
0721006
4
Screw, Machine #10-24NC x 3/4in
207
4751000
8
Flatwasher #10 Regular
208
3311005
4
Locknut #10-24NC
0258430
Ref
NOISE REDUCTION INSTALLATION (DEUTZ ENGINE
MACHINES)
2-B
301
2820099
3
Insulation, Foam
302
2820100
2
Insulation, Foam
