SECTION 2 - TURNTABLE
196
450A Series II/450AJ Series II
3121243
ITEM
PART NUMBER
QTY
DESCRIPTION
REV
16B
70000125
1
Receptacle, Single Twist Lock (220V Box)
16B
3520028
1
Plug, Hole
16C
Ref
Voltmeter Options:
16C
2420203
1
Voltmeter (110V)
16C
7020192
1
Voltmeter (220V)
16D
Ref
Pulley Options:
16D
3580324
1
Pulley (110V)
16D
3580325
1
Pulley (220V)
16D
7027887
1
Key, Woodruff
17
2820031
AR
Heatshrink (Not Shown - Located at Platform)
18
Ref
Decal Options:
18
3251243
1
Decal (110V)
18
1702590
1
Decal (220V)
19
3252764
1
Nameplate (Not Shown - Located at Platform)
20
3311005
2
Locknut # 10-24NC
21
3311405
1
Locknut 1/4in-20NC
22
3574225
1
Plate, Pulley Mounting
23
3580312
1
Pulley, Idler
24
3580313
1
Pulley, Grooved Idler
25
3740080
1
Relay, Bosch
26
3900322
2
Screw, Shoulder
27
4060802
1
Guard, Switch (Not Shown - Located at Platform)
28
4240018
AR
Tie-Strap (Not Shown)
29
4340738
1
Support, Idler Pulley
30
4360336
1
Switch, Toggle (Not Shown - Located at Platform)
31
4568734
1
Spacer, Tube (Idler Pulley Non-Grooved)
32
4568735
1
Spacer, Tube (Idler Pulley Grooved)
33
4711400
1
Flatwasher 1/4in Thin
34
4711700
2
Flatwasher 7/16in Thin
35
4740397
1
Spacer (Not Shown - Located at Platform)
36
4751000
2
Flatwasher #10 Regular
37
4751600
3
Flatwasher 3/8in Regular
38
4751800
1
Flatwasher 1/2in Regular
39
4891500
1
Flatwasher 5/16in Hardened
40
4891600
4
Flatwasher 3/8in Hardened
41
4892000
2
Flatwasher 5/8in Hardened
