SECTION 2 - TURNTABLE
3121243
450A Series II/450AJ Series II
209
ITEM
PART NUMBER
QTY
DESCRIPTION
REV
907
7007485
1
Spring
908
7021221
1
Screw
909
7007487
1
Guide, Spring
910
7007488
1
Ring, Retaining
911
7021222
1
Locknut
916
See Note
2
Ring, Piston (Note: Use Item 1601 or 1602.)
918
See Note
2
O-Ring (Note: Use Item 1601 or 1602.)
919
7021206
1
Nut, Jam
920
7021223
10
Screw
Ref
By-Pass Valve Group
1001
7007472
1
Valve, Bypass
1002
2900752
1
Ring, Back-Up
1003
2900752
1
O-Ring
Ref
Pressure Protection Group
1101
7021209
2
Plug Assembly
1102
2900752
2
O-Ring
1103
7021263
2
Valve, SCR
Ref
Control Group
1201
7023980
1
Control, Dual Oil-Filled
1201
7007496
1
Coil Assembly (Pilot)
1201
7007497
1
Plug (Pump)
1201
7007498
1
Plug (Valve Harness)
1202
2900752
1
O-Ring
1203
7007478
2
Screw
1204
7001498
2
Screw
1205
2900752
2
O-Ring
Ref
Control Orifice Group
1401
7007475
1
Plug, Orifice/Screen (.156)
1402
7021226
2
Plug, Orifice
Ref
Adapter Group
1502
0641608
5
Bolt
1503
7007476
1
Adapter, Auxiliary Pump
1504
7021298
1
Seal
1601
2900752
1
Seal Kit - Complete (Includes Items 103, 137, 141, 142, 168,
169, 301, 805, 916, 918, 1002, 1003, 1102, 1202, & 1205)
1602
7007412
1
Seal Kit - Servo Piston (Includes Items 916 & 918)
1603
2900826
1
Charge Pump Kit (Includes Items 141, 142, 155, 603, 604 & 605)
Ref
PUMP ASSEMBLY FITTINGS (3600406 PUMP ONLY)
A
1701
2110406
1
Fitting, Straight
1702
2111010
2
Fitting, Straight
1703
2111616
1
Fitting, Straight
1704
2131212
1
Fitting, Elbow
1705
2151616
2
Fitting, Elbow (Not Shown)
1706
2221084
1
Fitting, Tee
