SECTION 8 - DECALS
3121243
450A Series II/450AJ Series II
437
FIGURE 8-2. DECAL INSTALLATION - ANSI SPEC (USA BUILT MACHINES AND BELGIUM BUILT
MACHINES) (SN 0300069155 through 0300124000, SN 1300000001 through 1300006000)
ITEM
PART NUMBER
QTY
DESCRIPTION
REV
Ref
STANDARD DECAL INSTALLATION
0272573
Ref
450A/AJ Series II
7
0272530
Ref
JLG Logo Decals
1
1
1703797
1
Decal - Danger/Warning
2
1703798
1
Decal - Danger/Warning
3
1703805
2
Decal - Danger/Electrocution
4
1703804
3
Decal - Warning/Crushing
5
Ref
Decal - Legend Options:
5
1702784
1
USA Built Machines (SN 0300069155 through 0300099084)
5
1706931
1
USA Built Machines (SN 0300099085 through 0300124000)
5
1702784
1
Belgium Built Machines (SN 130000001 through 130000603)
5
1706931
1
Belgium Built Machines (SN 1300002604 through
1300006000)
6
Ref
Decal - Legend Options:
6
1703808
1
USA Built Machines (SN 0300069155 through 0300099084)
6
1706941
1
USA Built Machines (SN 0300099085 through 0300124000)
6
1703808
1
Belgium Built Machines (SN 130000001 through 1300002603)
6
1706941
1
Belgium Built Machines (SN 1300002604 through
1300006000)
9
1702774
3
Decal - JLG Lift (3 1/2in)
10
1702773
2
Decal - JLG (5in)
11
1702868
2
Decal - No Hands
12
1704277
3
Decal - Attach Lanyard Here
13
1701645
1
Decal - Max Capacity
14
Ref
Decal - Max Capacity
14
1702688
1
USA Built Machines (SN 0300069155 through 0300100315)
14
1707013
1
USA Built Machines (SN 0300100316 through 0300124000)
14
1702688
1
Belgium Built Machines (SN 130000001 through 1300002600)
14
1707013
1
Belgium Built Machines (SN 1300002601 through
1300006000)
15
3251813
1
Decal - USA
16
1701502
1
Decal - High Oil Level
17
1701503
1
Decal - Low Oil Level
18
1701504
2
Decal - Hydraulic Oil
19
1702153
1
Decal - Inspection
20
See Note
1
Decal - Bar Code (Note: Not available for purchase)
21
1700584
1
Decal - Patent
22
See Note
1
Nameplate - Serial Number (Note: Not available for purchase)
23
1701509
1
Decal - Manual
24
1702300
4
Decal - Tie Down /Lift
25
1701500
4
Decal - Tie Down /Lift
26
1701529
4
Decal- Arrow
27
3251243
1
Nameplate 120V-60Hz
28
0860520
1
Box, Manual Storage
29
1060279
1
Cable, Lanyard
30
0641408
1
Bolt 1/4in-20NC x 1in
31
4751400
6
Flatwasher 1/4in Regular
32
3311405
5
Locknut 1/4in-20NC
33
3820001
AR
Rivet
