SECTION 7 - ELECTRICAL
3121243 450A Series II/450AJ Series II 407
ITEM PART NUMBER QTY DESCRIPTION REV
4933218 Ref SOFT TOUCH ELECTRICAL DIAGRAM
Ref STANDARD ELECTRICAL DIAGRAMS
Ref Caterpillar Engine
4933280 Ref USA Built Machines (Prior to SN 0300087631)
4933332 Ref USA Built Machines (SN 0300087631 through 0300092619)
4933352 Ref USA Built Machines (SN 0300092620 through 0300099084)
4933382 Ref USA Built Machines (SN 0300099085 through 0300124000)
4933280 Ref Belgium Built Machines (Prior to SN 1300001008)
4933332 Ref Belgium Built Machines (SN 1300001008 through
1300001426)
4933352 Ref Belgium Built Machines (SN 1300001427 through
1300002603)
4933382 Ref Belgium Built Machines (SN 1300002604 through
1300006000)
Ref Deutz Engine
4933171 Ref USA Built Machines (Prior to SN 0300085629)
4933326 Ref USA Built Machines (SN 0300085629 through 0300099084)
4933384 Ref USA Built Machines (SN 0300099085 through 0300124000)
4933171 Ref Belgium Built Machines (Prior to SN 1300000979)
4933326 Ref Belgium Built Machines (SN 1300000979 through
1300002603)
4933384 Ref Belgium Built Machines (SN 1300002604 through
1300006000)
Ref Ford Engine
4933170 Ref USA Built Machines (Prior to SN 0300087631)
4933333 Ref USA Built Machines (SN 0300087631 through 0300124000)
Ref GM Engine
4933347 Ref USA Built Machines (Prior to SN 0300099085)
4933381 Ref USA Built Machines (SN 0300099085 through 0300124000)
4933382 Ref Perkins Engine (All Machines)
Ref STANDARD ELECTRICAL SCHEMATIC
Ref Caterpillar Engine Machines:
1870144 Ref USA Built (Prior to SN 0300116046)
1870215 Ref USA Built (SN 0300116046 through 0300124000)
1870144 Ref Belgium Built Machines (Prior to SN 1300004780)
1870215 Ref Belgium Built Machines (SN 1300004780 through
1300006000)
Ref Deutz Engine Machines:
1870144 Ref USA Built Machines (Prior to SN 0300085629)
1870191 Ref USA Built Machines (SN 0300085629 through 0300099084)
1870215 Ref USA Built Machines (SN 0300099085 through 0300124000)
1870144 Ref Belgium Built Machines (Prior to SN 1300000979)
1870191 Ref Belgium Built Machines (SN 1300000979 through
1300002603)
1870215 Ref Belgium Built Machines (SN 1300002604 through
1300006000)
1870144 Ref Ford Engine (All Machines)
Ref GM Engine Machines:
1870191 Ref USA Built Machines (Prior to SN 0300099085)
1870215 Ref USA Built Machines (SN 0300099085 through 0300124000)
1870215 Ref Perkins Engine (All Machines)
