SECTION 2 - TURNTABLE
3121243
450A Series II/450AJ Series II
203
FIGURE 2-23. 2500W GENERATOR INSTALLATION - PERKINS ENGINES (USA AND BELGIUM BUILT
MACHINES) (OPTIONAL)
ITEM
PART NUMBER
QTY
DESCRIPTION
REV
Ref
GENERATOR INSTALLATION
1001097325
Ref
110V/60Hz Generator (Available on all Specs Except
Australian and CE Specs)
C
1001097339
Ref
110V/50Hz Generator (Available on CE Specs Only)
B
1001097324
Ref
220V/50HZ Generator (Available on ANSI Export, Australian
and CE Specs)
B
Ref
Note: Refer to Sky Power Accessories Manual p/n 3124242 for
the Miller 7500W Generator.
1
0100011
AR
Compound, Locking
2
0200742
1
Arm, Adjusting
3
Ref
V-Belt Options:
3
0480121
1
V-Belt (110V)
3
0480120
1
V-Belt (220V)
4
0641508
1
Bolt 5/16in-18NC x 1in
6
0641772
1
Bolt 7/16in-14NC x 9in
7
0701217
3
Bolt M12 x 45mm
8
Ref
Generator and Control Box Assembly Options:
8
2460055
1
Generator and Control Box Assembly (110V/60Hz)
8
2460057
1
Generator and Control Box Assembly (110V/50Hz)
8
2460056
1
Generator and Control Box Assembly (220V/50Hz)
8A
Ref
Replacement Generator Only:
8A
7012558
1
Replacement Generator (110V/60Hz)
8A
2460049
1
Replacement Generator (110V/50Hz)
8A
1001100321
1
Replacement Generator (220V/50Hz)
Ref
Note: All Replacement Generators come standard with
P/N 3580134 Pulley. This Pulley may not be correct for
all applications. Refer to Pulley options below.
8A
7026199
1
110V/60Hz Armature with Slip Rings
8A
70000122
1
110V/50Hz Armature with Slip Rings
8A
70000123
1
220V/50Hz Armature with Slip Rings
8A
7020109
4
Holder, Brush
8A
7020108
4
Brush
8A
7012513
4
Cap, Brush Holder
8A
7012514
1
Fan
8A
7020190
2
Bearing
8A
7020110
1
End Bell, Front
8A
7020111
1
End Bell, Rear
8A
7020193
1
Cord, Power
8B
Ref
Control Box Options:
8B
7019680
1
Control Box (110V)
8B
70000127
1
Control Box (220V)
8B
Ref
Circuit Breaker Options:
8B
4360542
1
Circuit Breaker (110V)
8B
70000126
1
Circuit Breaker (220V)
8B
4460190
1
Receptacle, Double (110V Box)
8B
4460027
1
Receptacle, Double Twist Lock (110V Box)
8B
70000124
1
Receptacle, Double (220V Box)
8B
70000125
1
Receptacle, Single Twist Lock (220V Box)
8B
3520028
1
Plug, Hole
8C
Ref
Voltmeter Options:
