SECTION 2 - TURNTABLE

214

450A Series II/450AJ Series II

3121243

ITEM

PART NUMBER

QTY

DESCRIPTION

REV

85

7021298

1

Seal

86

7021299

1

Plate, Cover

87

7007289

2

Screw

88

7007470

1

Plug (Not Shown) (3600385 & 4640407 Pumps Only)

89

7021256

1

O-Ring (Not Shown) (3600385 & 4640407 Pumps Only)

95

7021280

1

Seal Kit (Includes Items 5-6, 22, 26, 30, 32, 42, 47-49, 53, 68-70,
73, 77, 82 & 89)

Ref

PUMP ASSEMBLY FITTINGS (3600407 PUMP ONLY)

C

101

2111010

2

Fitting, Straight

102

2111612

1

Fitting, Straight

103

2131212

1

Fitting, Elbow

104

2151616

2

Fitting, Elbow

105

2221084

1

Fitting, Tee
