SECTION 3 - BOOM
3121243
450A Series II/450AJ Series II
253
ITEM
PART NUMBER
QTY
DESCRIPTION
REV
SkyPower Only) (SN 1300002739 through 1300006000)
229
2221037
1
Fitting, Barbed (Not Shown - Used on Airline) (Machines with
SkyPower Only) (SN 1300002739 through 1300006000)
230
2720646
1
Hose, Airline (Not Shown) (Machines with SkyPower Only) (SN
1300002739 through 1300006000)
0272497
Ref
LIMIT SWITCHES INSTALLATION
D
301
0100011
AR
Compound, Locking
302
0641406
2
Capscrew, 1/4in-20NC x 3/4in
303
Ref
Cover, Switch Options:
303
1670998
1
Cover, Limit Switch (Prior to SN 1300004416)
303
1001096617
1
Shield, Limit Switch (SN 1300004416 through 1300006000)
304
1671086
1
Cover, Switch
305
3311005
4
Locknut #10-24NC
306
3931024
2
Capscrew, Socket Head #10-24NC x 1-1/2in
307
3931030
2
Capscrew, Socket Head #10-24NC x 1-7/8in
308
Ref
Switch, Limit Options:
308
4360321
1
Switch, Limit (Prior to SN 1300000175)
308
4360548
1
Switch, Limit - Plunger (SN 1300000175 through 1300006000)
309
4751400
2
Flatwasher, 1/4in Regular
310
4922714
1
Cable/Limit Switch Harness Assembly
310
1060902
8.5
ft/2.6m
Cable, Electrical 18/2 (Not Shown - See ELECTRICAL
SECTION)
310
4460226
2
Socket, Contact (Not Shown)
310A
Ref
Switch, Limit Options:
310A
4360321
1
Switch, Limit (Prior to SN 1300000133)
310A
4360548
1
Switch, Limit - Plunger (SN 1300000133 through 1300006000)
310B
Ref
Connector, Strain Relief
310B
4460428
1
Connector, Strain Relief (Prior to SN 1300000133)
310B
4460968
1
Connector, Strain Relief (SN 1300000133 through
1300006000)
311
4060803
8.5
in/217mm
Shield, Flex Trim (Not Shown)
312
Ref
Connector, Strain Relief Options:
312
4460428
1
Connector, Strain Relief (Prior to SN 1300000175)
312
4460968
1
Connector, Strain Relief (SN 1300000175 through 1300006000)
