SECTION 2 - TURNTABLE
3121243
450A Series II/450AJ Series II
191
FIGURE 2-20. 2500W GENERATOR INSTALLATION - FORD ENGINES (USA BUILT MACHINES)
(OPTIONAL) (Prior to SN 0300078473)
ITEM
PART NUMBER
QTY
DESCRIPTION
REV
Ref
GENERATOR INSTALLATION OPTIONS:
0271224
Ref
110V Generator (Prior to SN 0300078473)
4-C
0271226
Ref
220V Generator (Prior to SN 0300078473)
3-B
Ref
Note: Refer to SPECIAL OPTIONS SECTION for 7500W
Generator.
1
3580250
1
Pulley
2
Ref
Generator and Control Box Assembly Options:
2
2460032
1
110V/60Hz Assembly (Prior to SN 0300064407)
2
2460011
1
110V/60Hz Assembly (SN 0300064407 through 0300069627)
2
2460044
1
110V/60Hz Assembly (SN 0300069628 through 0300078472)
2
2460034
1
220V/50Hz Assembly (Prior to SN 0300064407)
2
2460013
1
220V/50Hz Assembly (SN 0300064407 through 0300078472)
2A
Ref
Generator Options:
2A
7012558
1
Generator (110V/60Hz)
2A
1001100321
1
Generator (220V/50Hz)
Ref
Note: All Replacement Generators come standard with
P/N 3580134 Pulley. This Pulley may not be correct for
all applications. Refer to Pulley options below.
2A
7026199
1
110V/60Hz Armature with Slip Rings
2A
70000123
1
220V/50Hz Armature with Slip Rings
2A
7020109
4
Holder, Brush
2A
7020108
4
Brush
2A
7012513
4
Cap, Brush Holder
2A
7012514
1
Fan
2A
7020190
2
Bearing
2A
7020110
1
End Bell, Front
2A
7020111
1
End Bell, Rear
2A
7020193
1
Cord, Power
2B
Ref
Control Box Options:
2B
7003657
1
Control Box (110V/60Hz)
2B
70002235
1
Control Box (220V/50Hz)
2B
Ref
Circuit Breaker Options:
2B
4360542
1
Circuit Breaker (110V)
2B
70000126
1
Circuit Breaker (220V)
2B
4460190
2
Receptacle, Double (110V Box)
2B
70000124
1
Receptacle, Double (220V Box)
2B
70000125
1
Receptacle, Single Twist Lock (220V Box)
2B
2920162
1
Lamp Assembly
2B
7020191
1
Switch, Toggle
2B
3520028
1
Plug, Hole
2C
Ref
Voltmeter Options:
2C
2420203
1
Voltmeter (110V)
2C
7020192
1
Voltmeter (220V)
2D
Ref
Pulley Options:
2D
Ref
Pulley (110V/60Hz)
2D
3580276
1
Pulley (Prior to SN 0300064407)
2D
3580134
1
Pulley (SN 0300064407 through 0300069627)
2D
3580307
1
Pulley (SN 0300069628 through 0300078472)
2D
Ref
Pulley (220V/50Hz)
