SECTION 7 - ELECTRICAL
406 450A Series II/450AJ Series II 3121243
FIGURE 7-1. ELECTRICAL DIAGRAM LIST
ITEM PART NUMBER QTY DESCRIPTION REV
0257887 Ref ALARM ELECTRICAL DIAGRAM
0258921 Ref ETHER START ELECTICAL DIAGRAM
1283002 Ref ETHER START ELECTICAL DIAGRAM
Ref GENERATOR ELECTRICAL DIAGRAM (2500W)
Ref Note: For Diagram for Machines with SkyPower Generator,
see JLG Supplement P/N 3124242.
Ref 110V (Caterpillar)
4933215 Ref USA Built Machines (Prior to SN 0300087209)
4933300 Ref USA Built Machines (SN 0300087209 through 0300124000)
Ref 110V (Deutz)
4933215 Ref USA Built Machines (110V/60Hz) (Prior to SN
SN0300077521)
4933250 Ref USA Built Machines (110V/50Hz) (Prior to SN 0300077521)
4933238 Ref USA Built Machines (SN 0300077521 through 0300082708)
4933300 Ref USA Built Machines (SN 0300082709 through 0300124000)
4933215 Ref Belgium Built machines (110V/60Hz) (Prior to SN
130000016)
4933250 Ref Belgium Built Machines (110V/50Hz) (Prior to SN
1300000316)
4933238 Ref Belgium Built Machines (SN 1300000316 through
1300000730)
4933300 Ref Belgium Built Machines (SN 1300000731 through
1300006000)
Ref 110V (Ford)
4933215 Ref USA Built Machines (Prior to SN 0300078473)
4933300 Ref USA Built Machines (SN 0300078473 through 0300124000)
4933350 Ref 110V (GM)
4933300 Ref 110V (Perkins)
Ref 220V (Caterpillar) (ANSI Export Only)
4933239 Ref USA Built Machines (Prior to SN 0300087208)
4933300 Ref USA Built Machines (SN 0300087209 through 0300124000)
Ref 220V (Deutz)
4933216 Ref USA Built Machines (Prior to SN 0300077521)
4933239 Ref USA Built Machines (SN 0300077521 through 0300082708)
4933300 Ref USA Built Machines (SN 0300082709 through 0300124000)
4933216 Ref Belgium Built Machines (Prior to SN 1300000316)
4933239 Ref Belgium Built Machines (SN 1300000316 through
1300000730)
4933300 1 Belgium Built Machines (SN 1300000731 through
1300006000)
Ref 220V (Ford)
4933216 Ref USA Built Machines (Prior to SN 0300078473)
4933300 Ref USA Built Machines (SN 0300078473 through 0300124000)
See Note Ref 220V (GM) (Note: Not Available)
4933300 Ref 220V (Perkins)
4933217 Ref GLOW PLUG ELECTICAL DIAGRAM (DEUTZ MACHINES)
Ref LIGHTS ELECTRICAL DIAGRAMS
4933219 Ref Headlights and Taillights
4933231 Ref Chassis Floodlights
0270814 Ref PLATFORM WORKLIGHTS ELECTRICAL DIAGRAM
