SECTION 8 - DECALS
3121243
450A Series II/450AJ Series II
459
FIGURE 8-7. DECALS INSTALLATION - AUSTRALIAN AND CE SPECS (USA BUILT MACHINES AND
BELGIUM BUILT MACHINES) (SN 0300074819 through 0300124000, SN 1300000180 through
1300006000)
ITEM
PART NUMBER
QTY
DESCRIPTION
REV
Ref
DECAL INSTALLATIONS
0272574
Ref
Australian Spec
4
0273452
Ref
CE Spec
3
0272530
Ref
JLG Logo Decals
1
1
Ref
Decal - Danger/Warning Options:
1
1703992
1
Australian Spec
1
1705821
1
CE Spec
2
Ref
Decal - Danger/Warning Options:
2
1705332
1
Australian Spec
2
1705822
1
CE Spec
4
1701518
3
Decal - Warning/Crushing
9
1702774
3
Decal - Lift (3 1/2in)
10
1702773
2
Decal - JLG (5 in)
12
1704277
3
Decal - Attach Lanyard
15
1705084
1
Decal - Sound Power Level (Not Required - Australian Spec)
16
1701502
1
Decal - High Oil Level
17
1701503
1
Decal - Low Oil Level
18
1701504
2
Decal - Hydraulic Oil
20
See Note
1
Decal - Bar Code (Note: Not available for purchase)
21
1700584
1
Decal - Patent
22
See Note
1
Nameplate - Serial Number (Note: Not available for purchase)
23
1701509
1
Decal - Manual
24
1702300
4
Decal - Tie Down /Lift
25
1701500
4
Decal - Tie Down /Lift
26
1701529
4
Decal - Arrow
27
Ref
Decal Options:
27
3251242
1
Decal (240V-50Hz - Australian Spec)
27
Not Required
0
CE Spec
28
0860520
1
Box, Manual Storage
29
1060279
1
Cable, Lanyard
30
0641408
1
Bolt 1/4in-20NC x 1in
31
4751400
6
Flatwasher 1/4in Regular
32
3311405
5
Locknut 1/4in-20NC
33
2080057
2
Fastener
34
Ref
Decal - Footswitch Options:
34
Not Required
0
Australian Spec
34
1705828
1
CE Spec
36
1701505
1
Decal - Fuel
43
1704412
1
Decal - Hydraulic Fluid
44
3252768
1
Decal - Lift Diagram
45
1704885
2
Decal - Website
46
0641406
4
Bolt, 1/4in-20NC x 3/4in (Not Shown)
47
1705821
1
Decal, Tipping/Elect (PLF) (Not Shown)
48
1705822
1
Decal, Elect/Safety Manual (MTB) (Not Shown)
0010578
Ref
DECAL OPTIONS
120
0272165
Ref
Warning Stripe Decal Installation
120
4420051
21.7
ft/6.61m
Decal - Warning Stripes
