SECTION 3 - BOOM
260
450A Series II/450AJ Series II
3121243
ITEM
PART NUMBER
QTY
DESCRIPTION
REV
59
4751500
6
Flatwasher 5/16in Regular
60
4751600
2
Flatwasher 3/8in Regular
61
4845927
2
Link, Jib (Lower)
62
4846278
1
Link, Jib (Upper)
67
4846356
1
Pivot, Jib
73
4220244
1
Stop
74
Ref
Cable, Electrical 18/2 Options (Not Shown):
74
4922770
1
Without Arctic Package
74
4923469
1
With Arctic Package
Ref
BOOM CABLES AND CLAMPS INSTALLATIONS
0271122
Ref
ANSI/ANSI Export/CSA Specs
J
0271206
Ref
Australian/CE Specs
J
0273280
Ref
All Specs with SkyPower
C
0275116
Ref
All Specs with Arctic Package
C
0275786
Ref
All Specs with Arctic Package and SkyPower
C
Ref
Note: For Additional Components See ELECTRICAL
SECTION
102
Ref
Block, Clamp Options:
102
0561459
2
Without Arctic Package
102
1321696
2
With Arctic Package
105
0641506
2
Bolt 5/16in-18NC x 3/4in (With SkyPower Only)
107
1320202
2
Clamp (With SkyPower Only)
112
3300151
6
Nut, Acorn 1/4in-20NC
114
3311401
6
Nut 1/4in-20NC
115
3311505
2
Locknut 5/16in-18NC (With SkyPower Only)
117
3571462
1
Shield
118
3574532
2
Plate, Clamp Mounting (With SkyPower Only)
130
4751400
12
Flatwasher 1/4in Regular
131
4751500
4
Flatwasher 5/16in Regular (With SkyPower Only)
134
Ref
Harness, Main Boom Options (Not Shown - See ELECTRICAL
SECTION):
134
4922532
1
Without Arctic Package
134
4923459
1
With Arctic Package
135
Ref
Cable, Electrical (Not Shown - See ELECTRICAL SECTION)
135
1060988
1
Without SkyPower (12/3 AC Power Cable)
135
4923481
1
With Arctic Package (12/3 AC Power Cable)
135
4922857
1
With SkyPower (8/5 AC Power Cable)
135
4923616
1
With Arctic Package with SkyPower(8/5 AC Power Cable) (Use
p/n 4922929) (Prior to SN 0300121049)
135
4922929
1
With Arctic Package with SkyPower(8/5 AC Power Cable) (SN
0300121049 through 0300124000)
