Advance Adapters AB1001 - Manual

P/N AB1000 32sp front output
Qty Part No. Description
ADVANCE ADAPTERS, INC.
4320 Aerotech Center Way, Paso Robles, CA 93446
ASSEMBLY INSTRUCTION SHEET
Page 1 of 12 Rev. Date: 07-14-10 P/N AB1000 & AB1001
P/N AB1001 26sp front output
Qty Part No. Description
ATLAS 2 SPEED REBUILD KITS
NOTE: We have not included the 32 spline yoke seals in these kits due to the two yoke diameters. These seals
must be ordered separtly. The caged bearing that fit the in the rear output shaft is not included in this kit, it is a
low wear bearing and is very difficult to remove.
1 300314 REAR OUTPUT BEARING
2 300355 CLUSTER THRUST WASHERS
2 300358 O-RING CLUSTER SHAFT
4 300370 BRAS SYNCRO RINGS
6 300372 SYNCRO DOGS
4 300373 SYNCRO DOR SPRINGSS
4 300383 SHIFT FORK PADS
2 300386 SET SCREW FOR SHIFT FORK
2 300387 SEAL FOR SHIFT RAIL
1 300393 FRONT OUTPUT THRUST WASHER
2 300474 RUBBER SEAL YOKE WASHER
2 300476 YOKE NUTS
3 300490 O-RING FOR INPUT AND OUTPUTS
6 300491 TAILHOUSING BEARING SHIMS
1 300499 FRONT INPUT SEAL
1 300500 FRONT INPUT SEAL
1 300509 FRONT OUTPUT THRUST WASHER
1 300510 FRONT INPUT BEARING
1 300511 FRONT OUTPUT BEARING
1 300512 FRONT OUTPUT BEARING
2 300513 REAR OUTPUT BEARING
1 300514 REAR OUTPUT BEARING
1 300515 OUTPUT SHAFT POCKET BEARING
2 300516 CLUSTER GEAR BEARINGS
2 300517 HIGH GEAR BEARINGS
2 300518 LOW SPEED GEAR BEARINGS
1 300919 DRAIN PLUG SEAL WASHER
1 301400 PAN GASKET
1 716453 SNAP RING
1 716455 SNAP RING
6 300105S FRONT HOUSING BEARING SHIMS
1 300314 REAR OUTPUT BEARING
2 300355 CLUSTER THRUST WASHERS
2 300358 O-RING CLUSTER SHAFT
4 300370 BRAS SYNCRO RINGS
6 300372 SYNCRO DOGS
4 300373 SYNCRO DOR SPRINGSS
4 300383 SHIFT FORK PADS
2 300386 SET SCREW FOR SHIFT FORK
2 300387 SEAL FOR SHIFT RAIL
1 300474 RUBBER SEAL YOKE WASHER
1 300476 YOKE NUTS
1 300478 FRONT YOKE NUT
1 300480 FRONT YOKE SEAL WASHER
3 300490 O-RING FOR INPUT AND OUTPUTS
6 300491 TAILHOUSING BEARING SHIMS
1 300499 FRONT INPUT SEAL
1 300500 FRONT INPUT SEAL
1 300501 FRONT OUTPUT SEAL
2 300509 FRONT OUTPUT THRUST WASHER
1 300510 FRONT INPUT BEARING
2 300511 FRONT OUTPUT BEARING
2 300512 FRONT OUTPUT BEARING
1 300513 REAR OUTPUT BEARING
1 300514 REAR OUTPUT BEARING
1 300515 OUTPUT SHAFT POCKET BEARING
2 300516 CLUSTER GEAR BEARINGS
2 300517 HIGH GEAR BEARINGS
2 300518 LOW SPEED GEAR BEARINGS
1 300919 DRAIN PLUG SEAL WASHER
1 301400 PAN GASKET
1 716453 SNAP RING
1 716455 SNAP RING
6 300105S FRONT HOUSING BEARING SHIMS
