6. Special Function Passwords (See section 5.2 for procedure on entering passwords)
6.1. Setting control message transmission requirements
DEC, INC, INC, INC, DEC, DEC, DEC, DEC
Engine control message is not transmitted when at idle (no mode selected) - displays message "NOTX AT IDLE" after
password is entered. This can be useful if there is more than one device on a vehicle which is controlling the RPM externally
over the CAN bus.
DEC, INC, INC, INC, DEC, DEC, DEC, INC
Engine control message is transmitted whenever the throttle interlock is active - displays message "TX AT IDLE" after
password is entered. This was the standard operation for TPG version 3.2 and below and is the default on newer versions.
6.2. Setting control for specific engine types
DEC, INC, DEC, INC, DEC, DEC, DEC, DEC
NORMAL_Engine = standard TSC1, no transmit at IDLE or without throttle ready interlock.
DEC, INC, DEC, INC, DEC, DEC, DEC, INC
NORMAL_Engine_2 = standard TSC1, but transmits at idle without throttle ready interlock.
DEC, INC, DEC, INC, DEC, DEC, INC, DEC
FAW_Engine = special TSC1, transmits at idle without throttle ready interlock, always "speed control".
DEC, INC, DEC, INC, DEC, DEC, INC, INC
FAW_Engine_2 = special TSC1, transmits at idle without throttle ready interlock, standard "override disabled" and
"speed control".
DEC, INC, DEC, INC, DEC, INC, DEC, DEC
MAN_Engine = special TSC1, no transmit at IDLE or without throttle ready interlock.
DEC, INC, DEC, INC, DEC, INC, DEC, INC
MAN_Engine_2 = special TSC1, but transmits at idle without throttle ready interlock.
6.3. Configuring transmission of Hydraulic Pressure Governor message
DEC, INC, INC, DEC, DEC, DEC, DEC, DEC
Transmit HPG message (default) - displays message "HPG = ON" after password is entered.
DEC, INC, INC, DEC, DEC, DEC, DEC, INC
Don't transmit HPG message - displays message "HPG = OFF" after password is entered.
DEC, INC, INC, DEC, INC, DEC, DEC, DEC
HPG message transmits mode normally - displays message "HPG MODE = NOR" after password is entered.
DEC, INC, INC, DEC, INC, DEC, DEC, INC
HPG message transmits PSI mode always - displays message "HPG MODE = PSI" after password is entered.
