MENU ITEM DESCRIPTION DEFAULT MENU LEVEL
XDCR Configures transducer type (300 or 600 psi) (300 default) 300 3
FACTORY DFLT
Returns all menu parameters to the factory default state
(Cummins Control – message type CFPG)
N/A 3
* Option dependent on other menu selections made
Menu items in menu level 4
MENU ITEM DESCRIPTION DEFAULT MENU LEVEL
POC ASSERT
Configures when idle offset is asserted (with power on cycle or mode
switch)
(Only available with message type ANLG)
NO 4*
GOV GAIN
Configures the RPM change requested per INC or DEC switch press
(Only available with message type ANLG)
15 4*
PRESS GAIN
Configures the pressure change requested per INC or DEC switch
press
3 PSI 4
DITHER
Configure the engine handshake
(Only available with message type PGN0)
NO 4*
LAG (
∆PSI) Controls the response of the pressure increase when the INC button
is held while in pressure mode.
5 PSI 4*
PUMP HOURS Set/reset the number of pump hours N/A 4
BCM1 VER
Configures the Scania BCM version
(Only available with message type SCAN)
1 4*
SCANIA MODE
Configures the Scania engine control type: NORMAL or STIFF
(Only available with message type SCAN)
NORMAL 4*
IDLE STEPS
Configures the idle offset voltage for analog control mode
(Only available with message type ANLG)
32 4*
* Option dependent on other menu selections made
Menu items in menu level 5
MENU ITEM DESCRIPTION DEFAULT MENU LEVEL
OK2PUMP Configure the “okay to pump” interlock source NORM 5
SPN 3350
Configure the PGN0 control purpose
(only available with message type PGN0)
P32 5*
SPN 696
Configure the Engine Requested Speed Control Condition
(only available with message type PGN0)
3 5*
HIDLE MODE Configure the high idle mode 1 5
BUS INTLKS Configure the bus interlocks N 5
VOLTS Calibrate the battery voltage display (+0.0 to +0.5 volts) +0.0 volts 5
SMOOTHING Configure pressure averaging (smoothing – NO, LO, HI) LO 5
ENGINE ID
Configure the CAN source ID where the TPG receives its engine
information from. Normally this will always be address 0 unless
some kind of interface module is used between the engine and TPG
0 5
* Option dependent on other menu selections made
