AEM Infinity Supported Applications - Universal V8 Engine - Manual (Page 40)

40
© 2014 AEM Performance Electronics
Infinity
Pin
Hardware Ref.
7100-XXXX-62
7101-XXXX-63
Function
Hardware Specification Notes
C1-42 +5V_Out_1 +5V Out
Regulated, f used +5V supply f or sensor
power
Analog sensor power
C1-43 HighsideSwitch_1*
HS1 (switched
12V)
0.7A max, High Side Solid State Relay
See Setup Wizard page 'HighSide
Assigment Tables' f or conf iguration
options. *Pin not populated in 30-3805
Univ ersal V8 Base harness.
C1-44 HighsideSwitch_0*
HS0 (switched
12V)
0.7A max, High Side Solid State Relay
See Setup Wizard page 'HighSide
Assigment Tables' f or conf iguration
options. *Pin not populated in 30-3805
Univ ersal V8 Base harness.
C1-45
Crankshaf t Position
Sensor VR+
Crankshaf t
Position Sensor
VR+
Dif f erential Variable Reluctance Zero
Cross Detection
See Setup Wizard page Cam/Crank f or
options.
C1-46
Crankshaf t Position
Sensor VR-
Crankshaf t
Position Sensor
VR-
See Setup Wizard page Cam/Crank f or
options.
C1-47
Camshaf t Position
Sensor 1 VR-
Camshaf t
Position Sensor
1 VR-
Dif f erential Variable Reluctance Zero
Cross Detection
See Setup Wizard page Cam/Crank f or
options.
C1-48
Camshaf t Position
Sensor 1 VR+
Camshaf t
Position Sensor
1 VR+
See Setup Wizard page Cam/Crank f or
options.
C1-49 VR+_In_2*
Non Driv en Lef t
Wheel Speed
Sensor +
Dif f erential Variable Reluctance Zero
Cross Detection
See Non Driv en Wheel Speed Calibration
in the Setup Wizard Input Function
Assignment page. *Pin not populated in
30-3805 Univ ersal V8 Base harness.
C1-50 VR-_In_2*
Non Driv en Lef t
Wheel Speed
Sensor -
C1-51 VR-_In_3*
Driv en Lef t
Wheel Speed
Sensor - Dif f erential Variable Reluctance Zero
Cross Detection
See Driv en Wheel Speed Calibration in
the Setup Wizard Input Function
Assignment page.
*Pin not populated in 30-3805 Univ ersal
V8 Base harness.
C1-52 VR+_In_3*
Driv en Lef t
Wheel Speed
Sensor +
C1-53 DBW1 Motor -*
DBW Motor
Control Close
5.0A max Throttle Control Hbridge Driv e
+12V to close. *Pin not populated in 30-
3805 Univ ersal V8 Base harness.
C1-54 DBW1 Motor +*
DBW Motor
Control Open
5.0A max Throttle Control Hbridge Driv e
+12V to open. *Pin not populated in 30-
3805 Univ ersal V8 Base harness.
C1-55 Power Ground Ground Power Ground Connect directly to battery ground.
C1-56 Injector 6 Injector 6
Saturated or peak and hold, 3A max
continuous
Injector 6
C1-57 Injector 5 Injector 5
Saturated or peak and hold, 3A max
continuous
Injector 5
C1-58 Injector 4 Injector 4
Saturated or peak and hold, 3A max
continuous
Injector 4
C1-59 Injector 3 Injector 3
Saturated or peak and hold, 3A max
continuous
Injector 3
C1-60 Power Ground Ground Power Ground Connect directly to battery ground.
