Infinity Supported Application 7
© 2014 AEM Performance Electronics
Infinity
Pin
Hardware Reference
7100-XXXX-62
7101-XXXX-63
Function
Dest. Pin
Honda K
Hardware Specification Notes
C1-10 +12V_R8C_CPU
Battery Perm
Power
Dedicated power management
CPU
Full time battery power. MUST be
powered bef ore the ignition switch input
is triggered. (See C1-65.)
C1-11 Coil 4 Coil 4 A27 25 mA max source current
0–5V Falling edge f ire. DO NOT
connect directly to coil primary . Must
use an ignitor OR CDI that accepts a
FALLING edge f ire signal.
C1-12 Coil 3 Coil 3 A28 25 mA max source current
0–5V Falling edge f ire. DO NOT
connect directly to coil primary . Must
use an ignitor OR CDI that accepts a
FALLING edge f ire signal.
C1-13 Coil 2 Coil 2 A29 25 mA max source current
0–5V Falling edge f ire. DO NOT
connect directly to coil primary . Must
use an ignitor OR CDI that accepts a
FALLING edge f ire signal.
C1-14 Coil 1 Coil 1 A30 25 mA max source current
0–5V Falling edge f ire. DO NOT
connect directly to coil primary . Must
use an ignitor OR CDI that accepts a
FALLING edge f ire signal.
C1-15 Coil 6 Coil 6 25 mA max source current
0–5V Falling edge f ire. DO NOT
connect directly to coil primary . Must
use an ignitor OR CDI that accepts a
FALLING edge f ire signal.
C1-16 Coil 5 Coil 5 25 mA max source current
0–5V Falling edge f ire. DO NOT
connect directly to coil primary . Must
use an ignitor OR CDI that accepts a
FALLING edge f ire signal.
C1-17 LowsideSwitch_2
Coolant Fan 1
Control
B6
Lowside switch, 4A max, NO
internal f ly back diode. See "LowSide Assignment Tables" f or
output assignment.
C1-18 LowsideSwitch_3 MIL Output E31
Lowside switch, 4A max with
internal f ly back diode. Inductiv e
load should NOT hav e f ull time
power.
See Wizard page "LowSide Assignment
Tables" f or output assignment.
MIL Activ ates when any of the
f ollowing f lags are true: ErrorAirTemp,
ErrorBaro, ErrorCoolantTemp, ErrorEBP,
ErrorFuelPressure,
UEGO_0_Diag_error,
UEGO_1_Diag_error, ErrorMAFAnalog,
ErrorMAFDigital, ErrorMAP,
ErrorOilPressure, ErrorThrottle.
C1-19 AGND_1 Sensor Ground A11 Dedicated analog ground Analog 0–5V sensor ground
C1-20 AGND_1 Sensor Ground A10 Dedicated analog ground Analog 0–5V sensor ground
C1-21
Crankshaf t Position
Sensor Hall
Crankshaf t
Position Sensor
Hall
A7
10K pullup to 12V. Will work with
ground or f loating switches. See Setup Wizard page Cam/Crank f or
options.
C1-22
Camshaf t Position
Sensor 1 Hall
Camshaf t
Position Sensor
1 Hall
A26
10K pullup to 12V. Will work with
ground or f loating switches. See Setup Wizard page Cam/Crank f or
options.
