PINOUTS

Infinity Pinouts

Dedicated

Dedicated and not reconfigurable

Assigned

Assigned but reconfigurable

Available

Available for user setup

Not Applicable

Not used in this configuration

Required

Required for proper function

Infinity

Pin

Hardware Reference

7100-XXXX-62
7101-XXXX-63

Function

Dest. Pin
Honda K

Hardware Specification

Notes

C1-1

LowsideSwitch_4

A/C Relay

Control

E18

Lowside switch, 4A max, NO
internal f ly back diode.

See "LowSide Assignment Tables" f or
output assignment.

C1-2

LowsideSwitch_5

LS5

Lowside switch, 4A max with
internal f ly back diode. Inductiv e
load should NOT hav e f ull time
power.

See Setup Wizard Page "LowSide
Assignment Tables" f or output
assignment and 2D table "LS5_Duty
[%]" f or activ ation.

C1-3

LowsideSwitch_6

LS6

A12

Lowside switch, 4A max with
internal f ly back diode. Inductiv e
load should NOT hav e f ull time
power.

See Setup Wizard Page "LowSide
Assignment Tables" f or output
assignment and 2D table "LS6_Duty
[%]" f or activ ation.

C1-4

UEGO 1 Heat

Bosch UEGO controller

Lowside switch f or UEGO heater
control. Connect to pin 4 of Bosch
UEGO sensor. NOTE that pin 3 of the
Sensor is heater (+) and must be power
by a f used/switched 12V supply .

C1-5

UEGO 1 IA

Trim Current signal. Connect to pin 2 of
Bosch UEGO sensor.

C1-6

UEGO 1 IP

Pumping Current signal. Connect to pin
6 of Bosch UEGO sensor.

C1-7

UEGO 1 UN

Nernst Voltage signal. Connect to pin 1
of Bosch UEGO sensor.

C1-8

UEGO 1 VM

Virtual Ground signal. Connect to pin 5
of Bosch UEGO sensor.

C1-9

Flash_Enable

Flash Enable

10K pulldown

Not usually needed f or automatic
f irmware updates through Inf inity
Tuner. If connection errors occur during
update, connect 12 v olts to this pin
bef ore proceeding with upgrade.
Disconnect the 12 v olts signal af ter the
update.
