Infinity Supported Application 11
© 2014 AEM Performance Electronics
Infinity
Pin
Hardware Reference
7100-XXXX-62
7101-XXXX-63
Function
Dest. Pin
Honda K
Hardware Specification Notes
C1-59 Injector 3 Injector 3 B3
Saturated or peak and hold, 3A
max continuous
Injector 3
C1-60 Power Ground Ground A4 Power Ground Connect directly to battery ground.
C1-61 +12V +12V In
B1 &
Splice
with +12V
f rom
Inf inity
Main
Relay
12 v olt power f rom relay
12 v olt power f rom relay . Relay must
be controlled by +12V Relay Control
signal, pin C1-29 abov e.
C1-62 Injector 2 Injector 2 B4
Saturated or peak and hold, 3A
max continuous
Injector 2
C1-63 Injector 1 Injector 1 B5
Saturated or peak and hold, 3A
max continuous
Injector 1
C1-64 +12V +12V In 12 v olt power f rom relay
12 v olt power f rom relay . Relay must
be controlled by +12V Relay Control
signal pin C1-29 abov e.
C1-65 +12V_SW Ignition Switch E9 10K pulldown
Full time battery power must be
av ailable at C1-10 bef ore this input is
triggered.
C1-66 Analog_In_Temp_1
Coolant Temp
Sensor
B8 12 bit A/D, 2.49K pullup to 5V
See "Coolant Temperature" Setup
Wizard f or selection.
C1-67 Analog_In_Temp_2
Intake Air
Temperature
B17 12 bit A/D, 2.49K pullup to 5V
See "Air Temperature" Setup Wizard f or
selection.
C1-68
Harness_Analog_In_Te
mp_3 Oil Temperature
Sensor
12 bit A/D, 2.49K pullup to 5V
See 1D table OilTempCal table f or
calibration data and OilTemp [C] f or
channel data.
C1-69 Stepper_2A Stepper 2A
Automotiv e, Programmable
Stepper Driv er, up to 28V and
±1.4A
Be sure that each internal coil of the
stepper motor is properly paired with
the 1A/1B and 2A/2B ECU outputs.
Supports Bi-Polar stepper motors only .
C1-70 Stepper_1A Stepper 1A
Automotiv e, Programmable
Stepper Driv er, up to 28V and
±1.4A
Be sure that each internal coil of the
stepper motor is properly paired with
the 1A/1B and 2A/2B ECU outputs.
Supports Bi-Polar stepper motors only .
C1-71 Stepper_2B Stepper 2B
Automotiv e, Programmable
Stepper Driv er, up to 28V and
±1.4A
Be sure that each internal coil of the
stepper motor is properly paired with
the 1A/1B and 2A/2B ECU outputs.
Supports Bi-Polar stepper motors only .
C1-72 Stepper_1B Stepper 1B
Automotiv e, Programmable
Stepper Driv er, up to 28V and
±1.4A
Be sure that each internal coil of the
stepper motor is properly paired with
the 1A/1B and 2A/2B ECU outputs.
Supports Bi-Polar stepper motors only .
