Infinity Supported Application 7
© 2014 AEM Performance Electronics
2) Enter in “Upper” values of DBW_Bias [%] 1d Table. Enter values for DBW_FB_Multiplier.
Note: Caution must be taken when tuning Drive By Wire values.
LowSide Assignment – Coolant Fans
In the Wizard LowSide Assignment tab confirm the following settings:
LS2 Setup:
Frequency = 30 Hz
LS2_Duty X-Axis = Engine Speed [RPM]
LS2_Duty Y-Axis = CoolantFan1On
LS8 Setup:
Frequency = 30 Hz
LS8_Duty X-Axis = Engine Speed [RPM]
LS8_Duty Y-Axis = CoolantFan2On
LowSide Assignment – VVC
In the VVC Wizard tab confirm the following settings:
VVC2A Enable = Checked
Cam 0 Sync = 95
Under “VVC2 Options” confirm the following settings:
VVC2 Failsafe Min = -55
VVC2 Failsafe Max = 5
VVC2 Feedback Min = -30
VVC2 Feedback Max = 30
VVC2 Duty Min = 0
VVC2 Duty Max = 90
VVC2 Proportional Gain = 0.950
VVC2 Integral Gain
= 2.500
VVC2 Derivative Gain = 0.050
In the Lowside Assignment Tables tab, configure LS5 as shown below:
Frequency = 250 Hz
LS5_Duty X-Axis = Engine Speed [RPM]
LS5_Duty Y-Axis = VVC2A_Duty [%]
Add a 2D table to the Infinity Tuner layout called “LS5_Duty [%] and configure it exactly as shown below.
