AEM Infinity Supported Applications - Dodge 2008-2010 Viper 4G - Manual (Page 15)

Infinity Supported Application 15
© 2014 AEM Performance Electronics
Infinity
Pin
Hardware Reference
08–10 Dodge
Viper Function
08–10
Dodge
Viper Pin
Destination
Hardware Specification Notes
C1-68
Harness_Analog_In_Te
mp_3 Oil Temperature
Sensor
C3-33
12 bit A/D, 2.49K pullup to
5V
See 1D table OilTempCal table f or
calibration data and OilTemp [C] f or
channel data.
C1-69 Stepper_2A Stepper 2A
Automotiv e, Programmable
Stepper Driv er, up to 28V
and ±1.4A
Be sure that each internal coil of the
stepper motor is properly paired with
the 1A/1B and 2A/2B ECU outputs.
Supports Bi-Polar stepper motors only .
C1-70 Stepper_1A Stepper 1A
Automotiv e, Programmable
Stepper Driv er, up to 28V
and ±1.4A
Be sure that each internal coil of the
stepper motor is properly paired with
the 1A/1B and 2A/2B ECU outputs.
Supports Bi-Polar stepper motors only .
C1-71 Stepper_2B Stepper 2B
Automotiv e, Programmable
Stepper Driv er, up to 28V
and ±1.4A
Be sure that each internal coil of the
stepper motor is properly paired with
the 1A/1B and 2A/2B ECU outputs.
Supports Bi-Polar stepper motors only .
C1-72 Stepper_1B Stepper 1B
Automotiv e, Programmable
Stepper Driv er, up to 28V
and ±1.4A
Be sure that each internal coil of the
stepper motor is properly paired with
the 1A/1B and 2A/2B ECU outputs.
Supports Bi-Polar stepper motors only .
C1-73 Power Ground Ground Power Ground Connect directly to battery ground.
C2-1 DBW2 Motor +
DBW Motor
Control Open
C2-8
5.0A max Throttle Control
Hbridge Driv e
+12V to open
C2-2 DBW2 Motor -
DBW Motor
Control Close
C2-18
5.0A max Throttle Control
Hbridge Driv e
+12V to close
C2-3 Power Ground Ground C3-31 Power Ground Connect directly to battery ground.
C2-4 Injector 7 Injector 7 C1-5
Saturated or peak and hold,
3A max continuous
Injector 7
C2-5 Injector 8 Injector 8 C2-13
Saturated or peak and hold,
3A max continuous
Injector 8
C2-6 Injector 9 Injector 9 C1-4
Saturated or peak and hold,
3A max continuous
Injector 9
C2-7 Injector 10 Injector 10 C2-12
Saturated or peak and hold,
3A max continuous
Injector 10
C2-8 Power Ground Ground
Pin 2 & 3 of
V23374-
A1601-X008
Relay
Power Ground Connect directly to battery ground.
C2-9 +12V +12V In
C2-19 / C2-
38
12 v olt power f rom relay
12 v olt power f rom relay . Relay must
be controlled by +12V Relay Control
signal, pin C1-29 abov e.
