AEM Infinity Supported Applications - Dodge 2008-2010 Viper 4G - Manual (Page 14)

14
© 2014 AEM Performance Electronics
Infinity
Pin
Hardware Reference
08–10 Dodge
Viper Function
08–10
Dodge
Viper Pin
Destination
Hardware Specification Notes
C1-52 VR+_In_3
Driv en Lef t
Wheel Speed
Sensor +
C1-53 DBW1 Motor -
DBW Motor
Control Close
C2-16
5.0A max Throttle Control
Hbridge Driv e
+12V to close
C1-54 DBW1 Motor +
DBW Motor
Control Open
C2-6
5.0A max Throttle Control
Hbridge Driv e
+12V to open
C1-55 Power Ground Ground C3-29 Power Ground Connect directly to battery ground.
C1-56 Injector 6 Injector 6 C2-4
Saturated or peak and hold,
3A max continuous
Injector 6
C1-57 Injector 5 Injector 5 C1-6
Saturated or peak and hold,
3A max continuous
Injector 5
C1-58 Injector 4 Injector 4 C2-14
Saturated or peak and hold,
3A max continuous
Injector 4
C1-59 Injector 3 Injector 3 C1-7
Saturated or peak and hold,
3A max continuous
Injector 3
C1-60 Power Ground Ground
C3-30 / Pins
4, 3, and
Capacitor of
TLE 5205-2G
Hbridge
Power Ground Connect directly to battery ground.
C1-61 +12V +12V In
C3-11 / C3-
20 / Pin 6 of
TLE 5205-2G
Hbridge
12 v olt power f rom relay
12 v olt power f rom relay . Relay must
be controlled by +12V Relay Control
signal, pin C1-29 abov e.
C1-62 Injector 2 Injector 2 C2-5
Saturated or peak and hold,
3A max continuous
Injector 2
C1-63 Injector 1 Injector 1 C2-11
Saturated or peak and hold,
3A max continuous
Injector 1
C1-64 +12V +12V In 12 v olt power f rom relay
12 v olt power f rom relay . Relay must
be controlled by +12V Relay Control
signal pin C1-29 abov e.
C1-65 +12V_SW Ignition Switch C1-12 10K pulldown
Full time battery power must be
av ailable at C1-10 bef ore this input is
triggered.
C1-66 Analog_In_Temp_1
Coolant Temp
Sensor
C3-24
12 bit A/D, 2.49K pullup to
5V See "Coolant Temperature" Setup
Wizard f or selection.
C1-67 Analog_In_Temp_2
Intake Air
Temperature
C3-1
12 bit A/D, 2.49K pullup to
5V See "Air Temperature" Setup Wizard f or
selection.
