Infinity Supported Application 13
© 2014 AEM Performance Electronics
Infinity
Pin
Hardware Reference
08–10 Dodge
Viper Function
08–10
Dodge
Viper Pin
Destination
Hardware Specification Notes
C1-40 Analog_In_12 Mode Switch
12 bit A/D, 100K pullup to
5V
0–5V analog signal. Use +5V Out pins
as power supply and Sensor Ground
pins as the low ref erence. Do not
connect signals ref erenced to +12V as
this can permanently damage the
ECU.
See the 1D lookup table 'ModeSwitch'
f or input state.
A multi-position rotary switch such as
AEM P/N 30-2056 is recommended.
Also assignable to multiple f unctions.
See Setup Wizard f or details.
C1-41 +5V_Out_1 +5V Out
C1-27 / +5V
of TLE 5205-
2G Hbridge
Regulated, f used +5V
supply f or sensor power
Analog sensor power
C1-42 +5V_Out_1 +5V Out C2-29
Regulated, f used +5V
supply f or sensor power
Analog sensor power
C1-43 HighsideSwitch_1
HS1 (switched
12V)
0.7A max, High Side Solid
State Relay
See Setup Wizard page 'HighSide
Assigment Tables' f or conf iguration
options. See 2D lookup table
'HS1_Table' f or activ ation settings.
C1-44 HighsideSwitch_0 VTEC
0.7A max, High Side Solid
State Relay
See Setup Wizard page 'HighSide
Assigment Tables' f or conf iguration
options.
See 2D lookup table 'HS0_Table' f or
activ ation settings.
See Setup Wizard page 'VTEC' f or
def ault activ ation criteria.
C1-45
Crankshaf t Position
Sensor VR+
Crankshaf t
Position Sensor
VR+ Dif f erential Variable
Reluctance Zero Cross
Detection
See Setup Wizard page Cam/Crank f or
options.
C1-46
Crankshaf t Position
Sensor VR-
Crankshaf t
Position Sensor
VR-
See Setup Wizard page Cam/Crank f or
options.
C1-47
Camshaf t Position
Sensor 1 VR-
Camshaf t
Position Sensor
1 VR- Dif f erential Variable
Reluctance Zero Cross
Detection
See Setup Wizard page Cam/Crank f or
options.
C1-48
Camshaf t Position
Sensor 1 VR+
Camshaf t
Position Sensor
1 VR+
See Setup Wizard page Cam/Crank f or
options.
C1-49 VR+_In_2
Non Driv en Lef t
Wheel Speed
Sensor + Dif f erential Variable
Reluctance Zero Cross
Detection
See Non Driv en Wheel Speed
Calibration in the Setup Wizard Input
Function Assignment page.
C1-50 VR-_In_2
Non Driv en Lef t
Wheel Speed
Sensor -
C1-51 VR-_In_3
Driv en Lef t
Wheel Speed
Sensor -
Dif f erential Variable
Reluctance Zero Cross
Detection See Driv en Wheel Speed Calibration in
the Setup Wizard Input Function
Assignment page.
