IMPORTANT APPLICATION SPECIFIC SETTINGS

Infinity Tuner Wizard Setup

Engine

In the Wizard Engine tab confirm the following settings:

Engine Displacement (L) = 8.40
Number of Cylinders

= 10

Engine Cycle Type

= 4 Stroke

Ignition Type

= Sequential (Coil On Plug)

Firing Order

= 1-10-9-4-3-6-5-8-7-2 Viper Odd Fire

Note: Throttle [%] was used for VE Table Load Axis Selection to create base session.

Cam/Crank

In the Wizard Cam/Crank tab confirm the following setting:

Dodge Viper V10 (2008–2010)

Ignition Sync

Add a text grid control to your layout and select the following channels. Make sure their values match
the settings below for initial timing sync.

TrigOffset [degBTDC]

= 4.50

CamSyncAdjustment

= 100.00

See QuickStart Guide section Setup: Ignition Sync for instructions on timing sync.

Injector Setup

In the Wizard Injector Setup tab confirm the following setting:

Number of Injectors = 10

Idle

In the Wizard Idle tab confirm the following settings:

Idle Stepper Max Steps = 33
Idle Airflow Invert

= Unchecked

DBW Tuning

1) Run Drive By Wire Wizard Setup.
