AEM 30-2340-N 4-Channel Wideband UEGO AFR Controller - For use with Nascar McLaren ECU User Manual
Page 27
Page 27
5 (bit1)
---
---
---
---
---
5 (bit2)
---
---
---
---
---
5 (bit3)
---
---
---
---
---
5 (bit4)
---
---
---
---
---
5 (bit5)
Sensor 6 Heating up
Boolean
0 = false, 1 = true
0
0/1
5 (bit6)
Sensor 5 Heating up
Boolean
0 = false, 1 = true
0
0/1
5 (bit7)
Sensor 4 Heating up
Boolean
0 = false, 1 = true
0
0/1
6
Exhaust Pressure 2
16 bit unsigned
.001 psig/bit
0
0 to 655.35 psig
7
