AEM 30-2340-N 4-Channel Wideband UEGO AFR Controller - For use with Nascar McLaren ECU User Manual
Page 26
Page 26
5 (bit3)
---
---
---
---
---
5 (bit4)
---
---
---
---
---
5 (bit5)
Sensor 3 Heating up
Boolean
0 = false, 1 = true
0
0/1
5 (bit6)
Sensor 2 Heating up
Boolean
0 = false, 1 = true
0
0/1
5 (bit7)
Sensor 1 Heating up
Boolean
0 = false, 1 = true
0
0/1
6
Exhaust Pressure 1
16 bit unsigned
.001 psig/bit
0
0 to 655.35 psig
7
Message ID:
0x000001B5
Source:
AEM 4 Channel UEGO set on MODE 7
Rate: 40ms
continuous
Byte
Label
Data Type
Scaling
Offset
Range
0 (bit0)
AFR 4 Ready
Boolean
0 = false, 1 = true
0
0/1
0 (bit1)
AFR 4 Heater Open Error
Boolean
0 = false, 1 = true
0
0/1
0 (bit2)
AFR 4 VM Error
Boolean
0 = false, 1 = true
0
0/1
0 (bit3)
AFR 4 UN Error
Boolean
0 = false, 1 = true
0
0/1
0 (bit4)
AFR 4 IP Error
Boolean
0 = false, 1 = true
0
0/1
0 (bit5)
AFR 4 Heater Time-Out Error
Boolean
0 = false, 1 = true
0
0/1
0 (bit6)
AFR 4 Heater Short Error
Boolean
0 = false, 1 = true
0
0/1
0 (bit7)
AFR 4 Overtemp Error
Boolean
0 = false, 1 = true
0
0/1
1 (bit0)
AFR 5 Ready
Boolean
0 = false, 1 = true
0
0/1
1 (bit1)
AFR 5 Heater Open Error
Boolean
0 = false, 1 = true
0
0/1
1 (bit2)
AFR 5 VM Error
Boolean
0 = false, 1 = true
0
0/1
1 (bit3)
AFR 5 UN Error
Boolean
0 = false, 1 = true
0
0/1
1 (bit4)
AFR 5 IP Error
Boolean
0 = false, 1 = true
0
0/1
1 (bit5)
AFR 5 Heater Time-Out Error
Boolean
0 = false, 1 = true
0
0/1
1 (bit6)
AFR 5 Heater Short Error
Boolean
0 = false, 1 = true
0
0/1
1 (bit7)
AFR 5 Overtemp Error
Boolean
0 = false, 1 = true
0
0/1
2 (bit0)
AFR 6 Ready
Boolean
0 = false, 1 = true
0
0/1
2 (bit1)
AFR 6 Heater Open Error
Boolean
0 = false, 1 = true
0
0/1
2 (bit2)
AFR 6 VM Error
Boolean
0 = false, 1 = true
0
0/1
2 (bit3)
AFR 6 UN Error
Boolean
0 = false, 1 = true
0
0/1
2 (bit4)
AFR 6 IP Error
Boolean
0 = false, 1 = true
0
0/1
2 (bit5)
AFR 6 Heater Time-Out Error
Boolean
0 = false, 1 = true
0
0/1
2 (bit6)
AFR 6 Heater Short Error
Boolean
0 = false, 1 = true
0
0/1
2 (bit7)
AFR 6 Overtemp Error
Boolean
0 = false, 1 = true
0
0/1
3
---
---
---
---
---
4 (bit0)
UEGO Low Voltage Error
Boolean
0 = false, 1 = true
0
0/1
4 (bit1)
EBP sensor ready
Boolean
0 = false, 1 = true
0
0/1
4 (bit2)
EBP sensor Error Low Volt
Boolean
0 = false, 1 = true
0
0/1
4 (bit3)
EBP sensor detected
Boolean
0 = false, 1 = true
0
0/1
4 (bit4)
CAN Config Mode
Boolean
0 = false, 1 = true
0
0/1
4 (bit5)
CAN Config Mode
Boolean
0 = false, 1 = true
0
0/1
4 (bit6)
CAN Config Mode
Boolean
0 = false, 1 = true
0
0/1
4 (bit7)
CAN Config Mode
Boolean
0 = false, 1 = true
0
0/1
5 (bit0)
---
---
---
---
---
