AEM 30-2340-N 4-Channel Wideband UEGO AFR Controller - For use with Nascar McLaren ECU - Manual (Page 18)

Page 18
Message ID: 0x00000022
Source: AEM 4 Channel UEGO set on MODE 4
Rate: 10ms continuous
Byte Label Data Type Scaling Offset Range
0
Lambda 2 16 bit unsigned .0001 Lambda/bit 0 0 to 6.5535 Lambda
1
2
Lambda 4 16 bit unsigned .0001 Lambda/bit 0 0 to 6.5535 Lambda
3
4
Lambda 6 16 bit unsigned .0001 Lambda/bit 0 0 to 6.5535 Lambda
5
6
Lambda 8 16 bit unsigned .0001 Lambda/bit 0 0 to 6.5535 Lambda
7
Message ID: 0x00000023
Source: AEM 4 Channel UEGO set on MODE 5
Rate: 10ms continuous
Byte Label Data Type Scaling Offset Range
0
Lambda 9 16 bit unsigned .0001 Lambda/bit 0 0 to 6.5535 Lambda
1
2
Lambda 10 16 bit unsigned .0001 Lambda/bit 0 0 to 6.5535 Lambda
3
4
Lambda 11 16 bit unsigned .0001 Lambda/bit 0 0 to 6.5535 Lambda
5
6
Lambda 12 16 bit unsigned .0001 Lambda/bit 0 0 to 6.5535 Lambda
7
Message ID: 0x00000024
Source: AEM 4 Channel UEGO set on MODE 6
Rate: 10ms continuous
Byte Label Data Type Scaling Offset Range
0
Lambda 1 16 bit unsigned .0001 Lambda/bit 0 0 to 6.5535 Lambda
1
2
Lambda 2 16 bit unsigned .0001 Lambda/bit 0 0 to 6.5535 Lambda
3
4
Lambda 3 16 bit unsigned .0001 Lambda/bit 0 0 to 6.5535 Lambda
5
6 --- --- --- --- ---
7 --- --- --- --- ---
Message ID: 0x00000025
Source: AEM 4 Channel UEGO set on MODE 7
Rate: 10ms continuous
Byte Label Data Type Scaling Offset Range
0
Lambda 4 16 bit unsigned .0001 Lambda/bit 0 0 to 6.5535 Lambda
1
