Byte Label Data Type Scaling Offset Range
0 (bit0)
AFR 9 Ready
Boolean 0 = false, 1 = true 0 0/1
0 (bit1)
AFR 9 Heater Open Error
Boolean 0 = false, 1 = true 0 0/1
0 (bit2)
AFR 9 VM Error
Boolean 0 = false, 1 = true 0 0/1
0 (bit3)
AFR 9 UN Error
Boolean 0 = false, 1 = true 0 0/1
0 (bit4)
AFR 9 IP Error
Boolean 0 = false, 1 = true 0 0/1
0 (bit5)
AFR 9 Heater Time-Out Error
Boolean 0 = false, 1 = true 0 0/1
0 (bit6)
AFR 9 Heater Short Error
Boolean 0 = false, 1 = true 0 0/1
0 (bit7)
AFR 9 Overtemp Error
Boolean 0 = false, 1 = true 0 0/1
1 (bit0)
AFR 10 Ready
Boolean 0 = false, 1 = true 0 0/1
1 (bit1)
AFR 10 Heater Open Error
Boolean 0 = false, 1 = true 0 0/1
1 (bit2)
AFR 10 VM Error
Boolean 0 = false, 1 = true 0 0/1
1 (bit3)
AFR 10 UN Error
Boolean 0 = false, 1 = true 0 0/1
1 (bit4)
AFR 10 IP Error
Boolean 0 = false, 1 = true 0 0/1
1 (bit5)
AFR 10 Heater Time-Out Error
Boolean 0 = false, 1 = true 0 0/1
1 (bit6)
AFR 10 Heater Short Error
Boolean 0 = false, 1 = true 0 0/1
1 (bit7)
AFR 10 Overtemp Error
Boolean 0 = false, 1 = true 0 0/1
2 (bit0)
AFR 11 Ready
Boolean 0 = false, 1 = true 0 0/1
2 (bit1)
AFR 11 Heater Open Error
Boolean 0 = false, 1 = true 0 0/1
2 (bit2)
AFR 11 VM Error
Boolean 0 = false, 1 = true 0 0/1
2 (bit3)
AFR 11 UN Error
Boolean 0 = false, 1 = true 0 0/1
2 (bit4)
AFR 11 IP Error
Boolean 0 = false, 1 = true 0 0/1
2 (bit5)
AFR 11 Heater Time-Out Error
Boolean 0 = false, 1 = true 0 0/1
2 (bit6)
AFR 11 Heater Short Error
Boolean 0 = false, 1 = true 0 0/1
2 (bit7)
AFR 11 Overtemp Error
Boolean 0 = false, 1 = true 0 0/1
3 (bit0)
AFR 12 Ready
Boolean 0 = false, 1 = true 0 0/1
3 (bit1)
AFR 12 Heater Open Error
Boolean 0 = false, 1 = true 0 0/1
3 (bit2)
AFR 12 VM Error
Boolean 0 = false, 1 = true 0 0/1
3 (bit3)
AFR 12 UN Error
Boolean 0 = false, 1 = true 0 0/1
3 (bit4)
AFR 12 IP Error
Boolean 0 = false, 1 = true 0 0/1
3 (bit5)
AFR 12 Heater Time-Out Error
Boolean 0 = false, 1 = true 0 0/1
3 (bit6)
AFR 12 Heater Short Error
Boolean 0 = false, 1 = true 0 0/1
3 (bit7)
AFR 12 Overtemp Error
Boolean 0 = false, 1 = true 0 0/1
4 (bit0)
UEGO Low Voltage Error
Boolean 0 = false, 1 = true 0 0/1
4 (bit1)
EBP sensor ready
Boolean 0 = false, 1 = true 0 0/1
4 (bit2)
EBP sensor Error Low Volt
Boolean 0 = false, 1 = true 0 0/1
4 (bit3)
EBP sensor detected
Boolean 0 = false, 1 = true 0 0/1
4 (bit4)
CAN Config Mode
Boolean 0 = false, 1 = true 0 0/1
4 (bit5)
CAN Config Mode
Boolean 0 = false, 1 = true 0 0/1
4 (bit6)
CAN Config Mode
Boolean 0 = false, 1 = true 0 0/1
4 (bit7)
CAN Config Mode
Boolean 0 = false, 1 = true 0 0/1
5 (bit0) --- --- --- --- ---
5 (bit1) --- --- --- --- ---
5 (bit2) --- --- --- --- ---
5 (bit3) --- --- --- --- ---
5 (bit4)
Sensor 12 Heating up
Boolean 0 = false, 1 = true 0 0/1
