AEM 30-2340-N 4-Channel Wideband UEGO AFR Controller - For use with Nascar McLaren ECU - Manual (Page 23)

Page 23
1 (bit0)
AFR 4 Ready
Boolean 0 = false, 1 = true 0 0/1
1 (bit1)
AFR 4 Heater Open Error
Boolean 0 = false, 1 = true 0 0/1
1 (bit2)
AFR 4 VM Error
Boolean 0 = false, 1 = true 0 0/1
1 (bit3)
AFR 4 UN Error
Boolean 0 = false, 1 = true 0 0/1
1 (bit4)
AFR 4 IP Error
Boolean 0 = false, 1 = true 0 0/1
1 (bit5) AFR 4 Heater Time-Out Error Boolean 0 = false, 1 = true 0 0/1
1 (bit6) AFR 4 Heater Short Error Boolean 0 = false, 1 = true 0 0/1
1 (bit7)
AFR 4 Overtemp Error
Boolean 0 = false, 1 = true 0 0/1
2 (bit0)
AFR 6 Ready
Boolean 0 = false, 1 = true 0 0/1
2 (bit1)
AFR 6 Heater Open Error
Boolean 0 = false, 1 = true 0 0/1
2 (bit2)
AFR 6 VM Error
Boolean 0 = false, 1 = true 0 0/1
2 (bit3) AFR 6 UN Error Boolean 0 = false, 1 = true 0 0/1
2 (bit4) AFR 6 IP Error Boolean 0 = false, 1 = true 0 0/1
2 (bit5) AFR 6 Heater Time-Out Error Boolean 0 = false, 1 = true 0 0/1
2 (bit6) AFR 6 Heater Short Error Boolean 0 = false, 1 = true 0 0/1
2 (bit7) AFR 6 Overtemp Error Boolean 0 = false, 1 = true 0 0/1
3 (bit0)
AFR 8 Ready
Boolean 0 = false, 1 = true 0 0/1
3 (bit1)
AFR 8 Heater Open Error
Boolean 0 = false, 1 = true 0 0/1
3 (bit2)
AFR 8 VM Error
Boolean 0 = false, 1 = true 0 0/1
3 (bit3)
AFR 8 UN Error
Boolean 0 = false, 1 = true 0 0/1
3 (bit4)
AFR 8 IP Error
Boolean 0 = false, 1 = true 0 0/1
3 (bit5) AFR 8 Heater Time-Out Error Boolean 0 = false, 1 = true 0 0/1
3 (bit6)
AFR 8 Heater Short Error
Boolean 0 = false, 1 = true 0 0/1
3 (bit7)
AFR 8 Overtemp Error
Boolean 0 = false, 1 = true 0 0/1
4 (bit0)
UEGO Low Voltage Error
Boolean 0 = false, 1 = true 0 0/1
4 (bit1)
EBP sensor ready
Boolean 0 = false, 1 = true 0 0/1
4 (bit2)
EBP sensor Error Low Volt
Boolean 0 = false, 1 = true 0 0/1
4 (bit3)
EBP sensor detected
Boolean 0 = false, 1 = true 0 0/1
4 (bit4)
CAN Config Mode
Boolean 0 = false, 1 = true 0 0/1
4 (bit5)
CAN Config Mode
Boolean 0 = false, 1 = true 0 0/1
4 (bit6)
CAN Config Mode
Boolean 0 = false, 1 = true 0 0/1
4 (bit7)
CAN Config Mode
Boolean 0 = false, 1 = true 0 0/1
5 (bit0) --- --- --- --- ---
5 (bit1) --- --- --- --- ---
5 (bit2) --- --- --- --- ---
5 (bit3) --- --- --- --- ---
5 (bit4)
Sensor 8 Heating up
Boolean 0 = false, 1 = true 0 0/1
5 (bit5)
Sensor 6 Heating up
Boolean 0 = false, 1 = true 0 0/1
5 (bit6)
Sensor 4 Heating up
Boolean 0 = false, 1 = true 0 0/1
5 (bit7)
Sensor 2 Heating up
Boolean 0 = false, 1 = true 0 0/1
6
Exhaust Pressure 2 16 bit unsigned .001 psig/bit 0 0 to 655.35 psig
7
Message ID: 0x000001B3
Source: AEM 4 Channel UEGO set on MODE 5
Rate: 40ms continuous
