5.16
[SOURce]:PULM Subsystem (Pulse Modulation)
This additional functionality provides pulse modulation of the RF output signal delivered to the load by
an internal or external modulation signal. The INTernal selection accesses the internally generated
modulation input while EXTernal selects the external pulse (rear panel connector) input.
Command
Parameters
Unit
(default)
[SOURce]:PULM:POLarity
NORMal | INVerted
NORMal
[SOURce]:PULM:INTernal:FREQuency
Hz
[SOURce]:PULM:INTernal:PERiod
s
[SOURce]:PULM:INTernal:PWIDth
s
[SOURce]:PULM:SOURce
INTernal|EXTernal|BI
TStream
INT
[SOURce]:PULM:STATe
ON|OFF|1|0
OFF
[SOURce]:PULM:MODE
FIXed | LIST
FIXed
[SOURce]:PULM:BITStream
5h
[SOURce]:PULM:BITStream:BITS
4
[SOURce]:PULM:BITStream:DIRection
MSBFirst | LSBFirst
MSBFirst
[SOURce]:PULM:BITStream:RATE
Hz
[SOURce]:PULM:BITStream:STARtbit
0
[SOURce]:PULM:BITStream:TIME
s
.:PULM:POLarity
[SOURce]:PULM:POLarity NORMal|INVerted
[SOURce]:PULM:POLarity?
This command selects the polarity of the pulse modulation, regardless if the internal or external
modulation source is used.
*RST Normal
:PULM:INTernal:FREQuency
[SOURce]:PULM:INTernal:FREQuency
[SOURce]:PULM:INTernal:FREQuency?
This command sets the pulse rate for the internally- generated square wave using the variable
*RST 400 Hz
Range INT: 0.1 Hz – 100 kHz, EXT: 0.1 Hz–10 MHz
:PULM:INTernal:PERiod
[SOURce]:PULM:INTernal:PERiod
