53
Ø 3.86 in.
(Ø 98.0 mm)
Ø 0.709 in.
(Ø 18.0 mm)
30°±10'
0.079 in.
(2.0 mm)
Ø 0.547 in.
(Ø
13.9 m
m)
13.8
15.55 in.
(395.0 mm)
THREAD: Ø 5/8" II UNC
13.78 in.
(350.0 mm)
0.079 in.
(20.0 mm)
0.197 in.
(5.0 mm
x 45°)
1.77 in.
(45.0 mm)
0.57 in.
(14.5mm) 0.078 in.
R 2.0
0.984 in.
R 5.0
Ø 3.15 in.
(Ø 80.0 mm)
Ø 0.79 in.
(Ø 20.0 mm)
Ø 1.97 in.
(Ø 50.0 mm)
0.39 in.
(10.0 mm x 45°)
4.53 in.
(115.0 mm)
2.44 in.
(62.0 mm)
1.77 in.
(45.0 mm)
Nut Lock
Special Tool
Section 6
Specifications
