Section 2 - Pre-Operation and Inspection
2-5 31200148
Safety Decals 3
OY1250
8060-3037-A
PINCH POINT
KEEP OUT
REACHING INTO BOOM HOLES AND OTHER PINCH POINTS CAN CAUSE SERIOUS INJURY OR DEATH.
91513210
9055-3026 REV. A
READ AND UNDERSTAND THE FOLLOWING PRIOR TO LIFTING PERSONNEL. WHEN LIFTING PERSONNEL USE ONLY A GRADALL MANUFACTURED PERSONNEL WORK PLATFORM. ALL PERSONNEL IN PLATFORM MUST WEAR A FULL BODY HARNESS WITH LANYARD ATTACHED TO A DESIGNATED ANCHORAGE POINT. READ AND UNDERSTAND PERSONNEL WORK PLATFORM USER'S MANUAL BEFORE OCCUPYING PERSONNEL WORK PLATFORM. FAILURE TO COMPLY COULD RESULT IN SERIOUS INJURY OR DEATH.
91513210
8060-3037-A
PINCH POINT
KEEP OUT
REACHING INTO BOOM HOLES AND OTHER PINCH POINTS CAN CAUSE SERIOUS INJURY OR DEATH.
91513210
-10° 0° 10° 20° 30° 40 ° 50 ° 60 ° 70 ° 80°
8060-3037-A
PINCH POINT
KEEP OUT
REACHING INTO BOOM HOLES AND OTHER PINCH POINTS CAN CAUSE SERIOUS INJURY OR DEATH.
9114-3290
ATTACHMENT MUST BE SECURED TO MACHINE. CHECK TO ASSURE QUICK SWITCH PLUNGER PIN IS FULLY ENGAGED AND LOCKED AFTER ATTACHMENT CHANGE. IF PLUNGER PIN IS NOT FULLY ENGAGED AND LOCKED ATTACHMENT MAY FALL OFF CAUSING SERIOUS INJURY OR DEATH.
9114-3282
STAY CLEAR OF PINCH POINT AREA
ANYTIME ENGINE IS RUNNING. BEING IN PINCH POINT AREA COULD
CAUSE SERIOUS INJURY OR DEATH.
91143282
-10 0 1020 30
40 50
60 7
08
0
4105262
80603037
91143290
8060-3037-A
PINCH POINT
KEEP OUT
REACHING INTO BOOM HOLES AND OTHER PINCH POINTS CAN CAUSE SERIOUS INJURY OR DEATH.
91513210
9114-3282
STAY CLEAR OF PINCH POINT AREA
ANYTIME ENGINE IS RUNNING.
BEING IN PINCH POINT AREA COULD CAUSE SERIOUS INJURY OR DEATH.
91143282
B B
VIEW B-B VIEW A-A
A
A
