OR-Fab 83223 JEEP JK WRANGLER / STUBBY FRONT BUMPER WITH HOOP AND OFFSET WINCH MOUNT - Manual (Page 7)

JK Wrangler HD Winch Bumper 7 Kit #83210/83220/83222/83211/83221/83223
Kit Parts List
Qty. Description
1 Bumper
1 Winch Plate
2 D-Ring Plate
1 Sideplate, Drvr
1 Sideplate, Pass
1 Hardware Pack
9 Bolt, Button Head (1/2”-13 x 1-1/4”)
4 Bolt, Button Head (1/2”-13 x 1-1/2”)
2 Bolt, Hex Head (1/2”-13 x 6”) *Centered only
1 Bolt, Hex Head (1/2”-13 x 6”) *Off set only
4 Bolt, Hex Head Gr. 8 (1/2”-13 x 1”)
10 Washer, Flat (1/2”)
18 Nut, Flange (1/2”-13)
2 Sleeve, (.75 x .090 x 4.275) *Centered only
2 Sleeve, (.75 x .090 x 4.275) *Off set only
4 Large Thick Washer
2 D-Rings
NOTE
All warranty information, instruction sheets, and other
documents regarding the installation of this product
must be retained by the vehicle owner. Information
contained in the instructions and on the warranty card
will be required for any warranty claims. The vehicle
owner needs to understand the modifications made to
the vehicle and how they affect vehicle handling and
performance. Failure to provide the customer with this
information can result in damage to the vehicle and
severe personal injury.
