FAST & FLUID MANAGEMENT
PAGE NO. 20 of 27
CW - V1.2 – 10- 05- 2012 (36609) – rev, B
V PREVENTITIVE MAINTENANCE
VI PREVENTITIVE MAINTENANCE
REMOVE SPLIT PIN
> >
Remove stirrer paddle from
canister and wash the canister,
lid and stirrer paddle clean If required, tighten or replace valve
insert sleeve (with the wrench
supplied). Take care not to over
tighten or sleeve with crack. Replace “O” ring seal – item 9
>
Reassemble and refit canister
to turntable Return colorant to dispenser
and prepare the pump for
operation (see chapter IV - A)
Attention! MOVING PARTS CAN CAUSE INJURY. Always turn off power
before accessing moving parts.
(8) Using a sharp knife or blade
cut any excess metalcal off the
end of the gauge that may
overlap the black plastic handle.
(9) Refit the gauge to the
plunger. Repeat steps (4)
through (9) for the inner
(red) gauge metalcal.
