Torrent SVS Valve Overhaul Kit
09/2005, Rev. -A
Parts Overhaul Kit
❑
7
SVS Valve Overhaul Kits
For installation instructions, see Torrent Installation and Service Main-
tenance Manual (p/n: 029-0020-90-0), Section 6, heading 6.3 “Servicing
the Valve,” beginning on page 27.
2-1/2” SVS Valve
Item #
Qty.
Part Number
Description
Level 1 Kit
p/n: 546-2290-01-0
Level 2 Kit
p/n: 546-2290-02-0
1
1
077-0780-21-0
Retaining Ring
•
•
1
077-9120-00-0
Retaining Ring (800 Series Valve)
•
•
2
2
040-1160-00-0
O-Ring, Stem
•
•
3
2
040-1550-00-0
O-Ring, Valve
•
•
4
2
159-1610-12-0
2.5” (64mm) Spacer, Valve Seat
•
5
2
276-0290-02-0
2.5” (64mm) Valve Seal
•
6
1
097-2310-25-0
Thrust Washer
•
7
1
250-9610-01-0
Valve Stem Bushing
•
3” SVS Valve
Item #
Qty.
Part Number
Description
Level 1 Kit
p/n: 546-2300-01-0
Level 2 Kit
p/n: 546-2300-02-0
1
1
077-0780-21-0
Retaining Ring
•
•
1
077-9120-00-0
Retaining Ring (800 Series Valve)
•
•
2
2
040-1160-00-0
O-Ring, Stem
•
•
3
2
040-1590-00-0
O-Ring, Valve
•
•
4
2
159-1610-13-0
3” (76mm) Spacer, Valve Seat
•
5
2
276-0290-03-0
3” (76mm) Valve Seal
•
6
1
097-2310-25-0
Thrust Washer
•
7
1
250-9610-01-0
Valve Stem Bushing
•
