200
PHYSICAL DATA (cont)
OPERATING AND RIGGING WEIGHTS — 581A155,180
*Base unit weight does not include electric heaters, copper coils, economizer, power exhaust, barometric relief or
crating. See Options and Accessories table below for more information.
NOTE: For 155 and 180 unit sizes add 75 lb (34 kg) for domestic crating. For export crating add 500 lb (227 kg).
OPTIONS AND ACCESSORIES — 581A155,180 (Weight Adders)
LEGEND
OPTIONS AND ACCESSORIES — 581A210-300 (Weight Adders)
LEGEND
UNIT
BASE UNIT OPERATING WEIGHTS*
155 180
lb kg lb kg
581A 1725 782 1800 816
OPTION/
ACCESSORY
OPTION/ACCESSORY WEIGHTS
48HJ015 48HJ017
lb kg lb kg
Barometric Relief Damper 50 23 50 23
Power Exhaust 85 39 85 39
EconoMi$er IV 90 41 90 41
EconoMi$er2 85 39 85 39
Cu Condenser Coil 150 68 150 68
Cu Condenser and Evaporator Coils 280 127 280 127
Roof Curb (14-in. curb) 200 91 200 91
Horizontal Adapter Roof Curb (Preassembled) 250 113 250 113
Horizontal Adapter Roof Curb (Field-assembled) 343 156 343 156
Hail Guard 60 27 60 27
Hot Gas Reheat Dehumidification Package — — 40 18
Cu — Copper
OPTION/
ACCESSORY
OPTION/ACCESSORY WEIGHTS
581A210 581A240 581A300
lb kg lb kg lb kg
Barometric Relief Damper 50 23 50 23 50 23
Power Exhaust 125 57 125 57 125 57
Economizer 170 77 170 77 195 88
Cu Condenser Coil 162 73 162 73 202 92
Cu Condenser and Evaporator Coils 316 143 290 132 365 166
5-Cell Gas Heat Assembly 85 39 85 39 85 39
8-Cell Gas Heat Assembly 113 51 113 51 113 51
Roof Curb (14 inch) 210 95 210 95 210 95
Optional Indoor Motor 28 13 28 13 20 9
Two-Position Damper 45 20 45 20 45 20
Hail Guard 85 39 85 39 100 45
Horizontal Airflow 90 41 90 41 90 41
Hot Gas Reheat 70 32 70 32 85 39
CO
2
Sensor 5 2 5 2 5 2
Return Smoke Detector 5 2 5 2 5 2
Supply Smoke Detector 5 2 5 2 5 2
Non-Fused Disconnect 15 7 15 7 15 7
Non-Powered Convenience Outlet 20 9 20 9 20 9
Enthalpy Sensor 2 1 2 1 2 1
Differential Enthalpy Sensor 3 1 3 1 3 1
Drip Edge 5 2 5 2 5 2
Manual Damper 25 11 25 11 25 11
Cu — Copper
HACR — Heating, Air Conditioning and Refrigeration
