69
G Wireless Modem Router
sections table of contents 1 2 3 4 5 6 7 9 10 8
TRoUblesHooTInG
Problem:
I am having difficulty setting up Wired Equivalent Privacy (WEP) security on a Belkin Wireless Card
solution:
The Wireless Card must use the same key as the Wireless Router or Access Point For instance, if your Wireless Router or Access Point uses the key
00112233445566778899AABBCC, then the Wireless Card must be set to the exact same key
1 Double-click the “Signal Indicator” icon to bring up the “Wireless
Network” screen
2 The “Advanced” button will allow you to view and configure more
options of the card
3 Once the “Advanced” button is clicked, the Belkin Wireless LAN
Utility will appear This Utility will allow you to manage all the
advanced features of the Belkin Wireless Card
4 Under the “Wireless Network Properties” tab, select a
network name from the “Available networks” list and click the
“Properties” button
5 Under “Data Encryption” select “WEP”
6 Ensure the check box “The key is provided for me automatically” at
the bottom is unchecked If you are using this computer to connect
to a corporate network, please consult your network administrator
if this box needs to be checked
7 Type your WEP key in the “Network key” box
IMPoRTanT: A WEP key is a mixture of numbers and letters from
A–F and 0–9 For 128-bit WEP, you need to enter 26 keys This
network key needs to match the key you assign to your Wireless
Router or Access Point
For example: C3 03 0F AF 4B B2 C3 D4 4B C3 D4 E7 E4 = 128-bit key
8 Click “OK”, and then “Apply” to save the settings
If you are NOT using a Belkin Wireless Card, please consult the
manufacturer for that card’s user manual
