KnoWInG YoUR RoUTeR
4 adsl – Green
OFF
Power off or ADSL line connection
is physically disconnected
Blinking
Handshaking or training is in progress
Solid
ADSL line connection is OK
5 Internet – Green
OFF
No Internet connection
Blinking
Transmitting or receiving data
Solid
Connected to the Internet
Rear Panel
The following figure illustrates the rear panel of your Router
(6)
(8)
(9)
(7)
