29
G Wireless Modem Router
sections table of contents 1 2 3 4 6 7 8 9 10 5
ManUallY ConfIGURInG YoUR RoUTeR
setting your Connection Type to Modem only (disable
Internet sharing)
In this mode, the Router simply acts as a bridge passing packets across
the DSL port It requires additional software to be installed on your
computers in order to access the Internet
1 VPI/VCI – Enter your VPI and VCI parameter here (Assigned by
your ISP)
2 encapsulation – Select LLC or VC MUX (Assigned by your ISP)
dns (domain name server) settings
A “Domain Name Server” is a server located on the Internet that
translates Universal Resource Links (URLs) like “wwwbelkincom” to IP
addresses Many ISPs do not require you to enter this information into
the Router The “Automatic from ISP” box (1) should be checked if your
ISP did not give you a specific DNS address If you are using a static IP
connection type, then you may need to enter a specific DNS address
and secondary DNS address for your connection to work properly If
your connection type is dynamic or PPPoE, it is likely that you do not
have to enter a DNS address
Leave the “Automatic from ISP” box checked To enter the DNS address
settings, uncheck the “Automatic from ISP” box and enter your DNS
entries in the spaces provided Click “Apply Changes” (2) to save
the settings
(1)
(2)
