60
G Wireless Modem Router
sections table of contents 1 2 3 4 5 7 8 9 10 6
ManUallY ConfIGURInG neTWoRK adaPTeRs
4 Select the “TCP/IP” tab (3) Next to “Configure” (4), you should see
“Manually” or “Using DHCP” If you do not, check the PPPoE tab
(5) to make sure that “Connect using PPPoE” is NOT selected If it
is, you will need to configure your Router for a PPPoE connection
type using your user name and password
6 If not already selected, select “Using DHCP” next to “Configure”
(4), then click “Apply Now”
5 If “Manually” is selected,
your Router will need to
be set up for a static IP
connection type Write the
address information in the
table below You will need
to enter this information into
the Router
Your network adapter(s) are now configured for use with the Router
