GETTING RECEIVER STATUS
When you are not in a menu, pressing ENTER will bring up a two or three line status message on Zone 1 (A)
video outputs. A single line status message is also available on the receiver’s front panel display. This display will
also pop up automatically whenever you change sources or whenever the selected source information changes.
The video type is very important if you are using mixed composite and S-video sources since it will tell you how
you must set your monitor for the best picture. The bitstream and channel information is particularly important with
DVDs since they may contain multiple soundtracks. When you initially start the DVD you may get a Dolby Digital
2.0 soundtrack. To get the best possible sound, you may have to use the DVD player’s menu system to get to a
Dolby Digital or DTS 5.1 channel soundtrack. If you ever need to call B&K regarding a problem with your receiver
be sure to note the status display before calling.
DVD Surround 7 EQ Variable
DVD AC3 5.1 48K Both Video
Dialog Normalization = 31
O N S C R E E N D I S P L A Y
'9'6855281'
F R O N T P A N E L D I S P L A Y
Used to indicate current bitstream type is
Dolby Digital and it is not set for use at a
dialog normalization level of -27 dB
The bitstream source
your receiver has detected
The current sample rate
of your receiver
The video types your
receiver has detected
The number of channels
your receiver has detected
The audio mode and speaker
selection you have chosen
The audio/video source
you have chosen
The current EQ
or
THX processing is on
The bitstream type your
receiver has detected
The audio mode and speaker
selection you have chosen
The audio/video source
you have chosen
recall receiver status ↵
(ENTER)
SEL or ENTER
Action From Front Panel From Remote
