B&K AVR307 User Manual

Page 33

Set the low pass filters slope -

SETUP CROSSOVERS + LFE
1 Crossover 80.0 Hz THX
2 High Pass 12.0 dB THX
3 Low Pass 24.0 dB THX
4 Peak Limiter 0.0 dB
5 LFE Level 0.0 dB
6 DTS LFE Mode Movie
7 Subwoofer Phase Normal

next item adjust
MENU setup speakers

3 Low Pass 24.0 dB THX

/2 3$66 '%

adjust filter slope to desired value

VOLUME KNOB

(REW) or

(FF)

move to Low Pass

∧

(UP) or

∨

(DOWN)

(PAUSE) or

(STOP)

Action

From Front Panel

From Remote

Set the peak limiter - The peak limiter is designed to limit the maximum level of bass information. When set to
0.0 dB (default) the limiter is disabled. If your system is being used with a subwoofer not incorporating it’s own
limiter or have no subwoofer, then the peak limiter may need to be set to allow proper operation.

Warning - the peak limiter test tone may result in extremely high volume levels

Peak limiter level calibration allows you to set the maximum obtainable volume sent to the speakers reproducing
bass information. For best results it is important that you perform this calibration when you initially install your
receiver, or whenever you change speakers. You set this parameter by ear using the test tone supplied when
entering the peak limiter. Sit in your normal listening spot. Check that you are in SETUP CROSSOVERS + LFE
and that your remote is in B&K mode. Moving to Peak Limiter and pressing SEL or ENTER activates a noise test
tone which will aid in adjusting the level to the point at which the bass speakers sound like they are having difficulty
reproducing the test tone. Once this level is achieved, reduce the adjustment 1 dB and press the SEL button on
the remote to save the peak limit setting. If the level is increased all the way to 0 dB with no perceived distortion,
then just leave the setting at 0 dB. If the correct values is known, the peak limiter may be set without the use of the
test tone.

SETUP CROSSOVERS + LFE
1 Crossover 80.0 Hz THX
2 High Pass 12.0 dB THX
3 Low Pass 24.0 dB THX
4 Peak Limiter 0.0 dB
5 LFE Level 0.0 dB
6 DTS LFE Mode Movie
7 Subwoofer Phase Normal
SEL to setup peak limiter
next item adjust
MENU setup speakers

4 Peak Limiter 0.0 dB

/,0,7

SETUP CROSSOVERS + LFE
1 Crossover 80.0 Hz THX
2 High Pass 12.0 dB THX
3 Low Pass 24.0 dB THX
4 Peak Limiter 0.0 dB
5 LFE Level 0.0 dB
6 DTS LFE Mode Movie
7 Subwoofer Phase Normal
SEL to save peak limiter
next item adjust
MENU setup speakers

4 Peak Limiter -24.0 dB

/,0,7

saves the peak limiter value

↵

(ENTER)

SEL or ENTER

adjust level to desired value
