LFE + Bass to SW
Surround Back Bass
is Duplicated
LFE + Bass to SW
Surround Bass is
Duplicated
LFE + Bass to SW
Center Bass is
Duplicated
LFE + Bass to SW
Front Bass is
Duplicated
Ultra
LFE + Bass to SW
Sb Bass not
Duplicated
LFE + Bass to SW
Surround Bass not
Duplicated
LFE + Bass to SW
Center Bass not
Duplicated
LFE + Bass to SW
Front Bass not
Duplicated
Yes
THX
LFE + Bass to
Surround Back
LFE + Bass to
Surround
LFE + Bass to
Center
LFE + Bass to
Front
None
Surround
Back Large
Surround
Large
Center
Large
Front
Large
Subwoofer Setting
Note: The subwoofer setting affects the routing of front, center, and surround bass information as shown
previously. This table shows the effect of the subwoofer setting with large speakers.
Speaker Location
Ideally your speakers will be the same distance away from your listening area. However, physical limitations
usually require placing the speaker in other than optimum locations. Your receiver contains a means to
electronically move each speakers location. This allows for superior reproduction of the directional cues available
during the playback of movie or music. Measure the distance in feet to your speakers and set each speaker
location setting to this distance. Your receiver will electronically “move” each speaker to maintain correct time
alignment with the listening position. You may also change the units to meters, if you prefer.
SETUP SPEAKERS
1 Speaker Size
2 Speaker Location
3 Speaker Levels
4 Crossovers + LFE
next item SEL select
MENU setup system
2 Speaker Location
SPEAKER LOCATION feet
1 Left Front 10.0
2 Center 10.0
3 Right Front 10.0
4 Right Surround 10.0
5 Right Surr Back 5.0
6 Left Surr Back 5.0
7 Left Surround 10.0
8 Subwoofer 10.0
next item adjust
MENU setup speakers
1 Left Front 10.0
63($.(5 /2&$7,21 /()7 )URQW
return to SETUP SPEAKERS
∠
MENU MENU 8
repeat for all speakers repeat 5-6 for each speaker repeat 5-6 for each speaker 7
adjust center speaker location VOLUME KNOB ˆ
(REW) or
‡
(FF) 6
move to Center ∧
(UP) or
∨
(DOWN) ­ (PAUSE) or V (STOP) 5
adjust left speaker location VOLUME KNOB
ˆ
(REW) or
‡
(FF) 4
move to Left Front ∧
(UP) or
∨
(DOWN)
­
(PAUSE) or
V
(STOP) 3
activate SPEAKER LOCATION ↵
(ENTER) SEL or ENTER 2
move to Speaker Location
∧
(UP) or
∨
(DOWN)
­
(PAUSE) or
V
(STOP) 1
Action From Front Panel From Remote
