88

Bradyprinter 200M-e and 200M-e 300 User’s Guide

0HGLD 6SHFLILFDWLRQV

*

Media registration and minimum label length are affected by media type and width, ribbon type, print

speed, and printer mode of operation. Performance improves as these factors are optimized. Brady
recommends always qualifying any application with thorough testing.

Media Specifications

200M-e/200M-e 300

Minimum label length*

Tear-off

0.7" (18 mm)

Peel-off

0.5" (13 mm)

Cutter

1.5" (38 mm)

Rewind

0.25" (6 mm)

Total media width (label + liner, if any)

Minimum

0.79" (20 mm)

Maximum

4.52 mm (115 mm)

Total thickness (includes liner, if any)

Minimum

0.003" (0.076 mm)

Maximum

0.012" (0.305 mm)

Cutter maximum full-width media thickness

0.009" (.23 mm)

Roll media core inside diameter

3" (76 mm)

Maximum roll diameter

8.0" (203 mm)

Inter-label gap

Minimum

0.079" (2 mm)

Preferred

0.118" (3 mm)

Maximum

Maximum inter-label gap =

2 x (label length for which you have

calibrated the printer) + 1"

Maximum internal fanfold media pack size (label + liner)
L x W x H

8.0" x 4.5" x 4.5"

(203 mm x 114 mm x 114 mm)

Ticket/tag sensing notch L x W

0.12" x 0.25" (3 mm) x (6 mm)

Ticket/tag sensing hole diameter

0.125" (3 mm)

Additional specifications for
black mark sensing

Mark length
(measuring parallel to
label/tag edge)

Minimum

0.12" (3 mm)

Maximum

0.43" (11 mm)

Mark width (measuring
to perpendicular label/
tag edge)

Minimum

0.43" (

11 mm)

Maximum

Full media width

Mark location

Marks must be located within 0.040" (1 mm)

of the inside media edge.

Mark density

>1.0 Optical Density Unit (ODU)

Maximum density of the back of the media
on which the black mark is printed

0.5 ODU
