Bradyprinter 200M-e and 200M-e 300 User’s Guide

17

0HGLD DQG 5LEERQ &DOLEUDWLRQ

NOTE: All steps must be performed in the following procedure,
even if only one sensor needs to be adjusted.

1. Press the SETUP/EXIT key.

2. Press the NEXT/SAVE key until “MEDIA AND RIBBON

CALIBRATE” displays.

3. To start the calibration procedure, press the (+) key. “LOAD

BACKING CANCEL CONTINUE” displays.

4. Open the printhead. Remove approximately 8" (203 mm) of labels

from the media roll, enough so that only the backing material is
threaded between the media sensors when the media is loaded
(refer to Figure 10).

Figure 10
