Bradyprinter 200M-e and 200M-e 300 User’s Guide 79
PAUSE Key Self Test
This self test can be used to provide the test labels required when making
adjustments to the printer’s mechanical assemblies; these test labels also
ensure the printhead has been aligned correctly after it has been adjusted.
See the sample printout in Figure 32.
1. Turn off the printer.
2. Press and hold the PAUSE key while turning on the power.
• The initial self test prints 15 labels at 2.4"/61 mm per second, then
automatically pauses the printer. When the PAUSE key is pressed,
an additional 15 labels print.
• While the printer is paused, pressing the CANCEL key alters the
self test. When the PAUSE key is pressed, the printer prints 15
labels at 6"/152 mm per second.
• While the printer is paused, pressing the CANCEL key again alters
the self test again. When the PAUSE key is pressed, the printer
prints 50 labels at 2.4"/61 mm per second.
• While the printer is paused, pressing the CANCEL key again alters
the self test a third time. When the PAUSE key is pressed, the
printer prints 50 labels at 6"/152 mm per second.
• While the printer is paused, pressing the CANCEL key again alters
the self test a fourth time. When the PAUSE key is pressed, the
printer prints 15 labels at the printer’s maximum speed.
• To exit this self test at any time, press and hold the CANCEL key.
Figure 32
