Neff C67P70N3GB User Manual
Neff Mini computers
Table of contents
Document Outline
- [en] Instruction manual
- Table of contents[en] Instruction manual
- Energy and environment tips 7
- Your new appliance 7
- Your accessories 8
- Before using the appliance for the first time 9
- Switching the appliance on and off 10
- Operating the appliance 10
- The microwave 12
- Combination 13
- Series of operations 13
- Memory 14
- Electronic clock 14
- Childproof lock 16
- Auto start 17
- Basic settings 17
- Pyrolytic cleaning 17
- Care and cleaning 18
- Faults and repairs 20
- After-sales service 22
- Automatic programmes 22
- Tested for you in our cooking studio 28
- Slow cooking 37
- Test dishes 38
- Acrylamide in foodstuffs 40
- : Important safety information
- Read these instructions carefully. Only then will you be able to operate your appliance safely and correctly. Retain the instruction manual and installation instructions for future use or for subsequent owners.
- This appliance is only intended to be fully fitted in a kitchen. Observe the special installation instructions.
- Check the appliance for damage after unpacking it. Do not connect the appliance if it has been damaged in transport.
- Only a licensed professional may connect appliances without plugs. Damage caused by incorrect connection is not covered under warranty.
- This appliance is intended for domestic use only. The appliance must only be used for the preparation of food and drink. The appliance must be supervised during operation. Only use this appliance indoors.
- This appliance may be used by children over the age of 8 years old and by persons with reduced physical, sensory or mental capabilities or by persons with a lack of experience or knowledge if they are supervised or are instructed by a person responsi...
- Children must not play with, on, or around the appliance. Children must not clean the appliance or carry out general maintenance unless they are at least 8 years old and are being supervised.
- Keep children below the age of 8 years old at a safe distance from the appliance and power cable.
- Always slide accessories into the cooking compartment correctly. See "Description of accessories in the instruction manual.
- Risk of fire!
- ■ Combustible items stored in the cooking compartment may catch fire. Never store combustible items in the cooking compartment. Never open the appliance door if there is smoke inside. Switch off the appliance and unplug it from the mains or switch ...
- Risk of fire!
- Risk of fire!
- Risk of fire!
- Risk of fire!
- Risk of fire!
- Risk of fire!
- Risk of explosion!
- Risk of serious damage to health!
- ■ The surface of the appliance may become damaged if it is not cleaned properly. Microwave energy may escape. Clean the appliance on a regular basis, and remove any food residue immediately. Always keep the cooking compartment, door seal, door and ...
- Risk of serious damage to health!
- Risk of serious damage to health!
- Risk of serious damage to health!
- Risk of serious damage to health.!
- Risk of electric shock!
- ■ Incorrect repairs are dangerous. Repairs may only be carried out and damaged power cables replaced by one of our trained after-sales technicians. If the appliance is defective, unplug the appliance from the mains or switch off the circuit breaker...
- Risk of electric shock and serious injury!
- Risk of electric shock!
- Risk of electric shock!
- Risk of electric shock!
- Risk of electric shock!
- Risk of electric shock!
- Risk of burns!
- ■ The appliance becomes very hot. Never touch the interior surfaces of the cooking compartment or the heating elements. Always allow the appliance to cool down. Keep children at a safe distance.
- Risk of serious burns!
- Risk of burns!
- Risk of burns!
- Risk of burns!
- Risk of burns!
- Risk of burns!
- Risk of burns!
- Risk of burns!
- Risk of scalding!
- Risk of injury!
- Hazard due to magnetism!
- Causes of damage
- Caution!
- ■ Creation of sparks
- ■ Baking tray, greaseproof paper, aluminium foil or ovenware on the cooking compartment floor
- ■ Foil containers
- ■ Water in the hot cooking compartment
- ■ Moist food
- ■ Fruit juice
- ■ Cooling with the appliance door open
- ■ Condensation in the cooking compartment
- ■ Heavily soiled seal
- ■ Using the appliance door for standing on or placing objects on
- ■ Transporting the appliance
- ■ Operating the microwave without food
- ■ Microwave popcorn
- Energy and environment tips
- Caution!
- Environmentally-friendly disposal
- Operating modes
- Cooking compartment
- After-sales service products
- Heating up the cooking compartment
- Cleaning the accessories
- Switching off
- Setting the operating mode and temperature
- MicroCombi, gentle / MicroCombi, intensive
- MicroCombi, gentleà
- Note
- MicroCombi, intensiveá
- Note
- Setting procedure
- 1. Using the rotary selector, set the “MicroCombi, gentle” or “MicroCombi, intensive” heating type.
- 2. Use the temperature selector to set the temperature.
- 3. Press the clock function button à repeatedly until the KJ and x symbols light up.
- 4. Change the cooking time using the rotary selector.
- 5. Press the ƒ button.
- Heating indicator
- Setting rapid heating
- Microwave power settings
- Setting the microwave
- Suitable microwave power settings
- Setting a combination
- Ovenware
- Setting a series of operations
- Storing settings in the memory
- Starting the memory
- Minute minder
- Cooking time
- End of operation
- Preset operation
- 1. Set the operating mode and temperature.
- 2. Press the clock function button à repeatedly until the KJ and x symbols light up.
- 3. Set the cooking time using the rotary selector (e.g. ‚:„‹ hours).
- 4. Press the clock function button à repeatedly until the KJ and y symbols light up.
- 5. Set the end of operation using the rotary selector (e.g. ‚ƒ:„‹).
- 6. Press the ƒ button.
- Setting the clock
- 1. Press the clock function button à repeatedly until the KJ and 3 symbols light up.
- 2. Turn the rotary selector to set the current time.
- 2. Press and hold the Info button ±.
- 3. Press the Info button ± again.
- 4. Turn the temperature selector until ™‚‚ appears on the temperature display.
- 2. Press and hold the ± Info button until ™‚‚ appears on the temperature display.
- 3. Turn the temperature selector until ™‚‹ appears on the temperature display.
- Permanent lock
- Locking the appliance permanently
- 1. Press the operating mode selector.
- 2. Press and hold the Info button ±.
- 3. Press the Info button ± again.
- 4. Turn the temperature selector until ™ƒ‚ appears on the temperature display.
- 5. Press and hold the Info button ±.
- 2. Press and hold the ± Info button until ™ƒ‚ appears on the temperature display.
- 3. Turn the temperature selector until ™ƒ‹ appears on the temperature display.
- 4. Press and hold the ± Info button until the ‚ symbol goes out.
- 5. Switch the appliance on within 30 seconds.
- 2. Press and hold the ± Info button until ™ƒ‚ appears on the temperature display.
- 3. Turn the temperature selector until ™ƒ‹ appears on the temperature display.
- 4. Press and hold the ± Info button until the ‚ symbol goes out.
- 5. Within 30 seconds, press and hold the ± Info button again for a few seconds.
- 6. Turn the temperature selector until ™‚‹ appears on the temperature display.
- 7. Press and hold the Info button ±.
- Automatic safety cut-out
- Changing the basic settings
- Preparation
- Setting pyrolytic cleaning
- After cleaning
- Cleaning agents
- Cleaning the glass panels
- Removal
- 2. Undo the two screws on the door using a TORX screwdriver (TORX 20). Hold the door panel firmly while doing this (Fig. A).
- 3. Close the door slowly and pull out the panel upwards by the door handle. (Fig. B)
- 4. Hold the intermediate panel firmly and unscrew the retaining clips on the door. Slide the panel upwards and out. (Fig. C).
- 5. Do NOT unscrew the left and right-hand screws from the sheet metal part (Fig. D).
- 2. The lettering must be positioned in the top right corner, so that it can be easily read. (Fig. B).
- 3. Tighten the retaining clips on the right and left of the panel using a TORX screwdriver (TORX 20). (Fig. C)
- 4. Insert the door panel into the guide with both hands. (Fig. D).
- 5. Push the door panel downwards, lift it slightly and hook it in at the top (Fig. E).
- 6. Fully open the door, while holding the panels firmly with one hand (Fig. F).
- 7. Push the door downwards again and tighten the screws hand-tight using a TORX screwdriver (TORX 20) and close the door. (Fig. G).
- Replacing the oven light bulb
- Note
- Method
- 2. Place a tea towel in the cold oven to prevent damage.
- 3. Remove the glass cover. To do this, open the glass cover at the bottom with your hand. Should you experience difficulties removing the glass cover, use a spoon to help. (Fig. A).
- 4. Remove the bulb and replace with a bulb of the same type. (Fig. B).
- 5. Refit the glass cover. (Fig. C).
- 6. Remove the tea towel.
- Replacing the door seal
- Selecting a programme
- 1. Pop out the operating mode selector.
- 2. Press the X button.
- 3. Select the desired programme group using the operating mode selector.
- 4. Press the  button.
- 5. Turn the operating mode selector until the matching programme appears.
- 6. Using the temperature selector, set the weight of the food.
- 7. Press the ƒ button.
- Adjusting individually
- Defrosting and cooking with the automatic programmes
- Cakes and pastries
- Roasting and grilling
- About the tables
- Ovenware
- Tips for roasting
- Tips for grilling
- Tips for braising
- Beef
- Veal
- Pork
- Lamb and game
- Miscellaneous
- Fish
- Tips for roasting and grilling
- Bakes, gratins, toast with toppings
- Convenience products
- Slow cooking
- 2. Select / low-temperature cooking and a temperature between 70 and 100 °C. Preheat the cooking compartment, thus warming the ovenware at the same time.
- 3. Remove fat and sinews from the meat.
- 4. Sear the meat on all sides to seal it and to create a roasted flavour.
- 5. When a signal sounds and “In operation” appears in the text display, place the meat on the glass or porcelain plate in the cooking compartment.
- Slow cooking
- Tips for slow cooking
