16 User’s Manual Multi Media Port Replicator
User's Manual – Port_Rep.doc – PART 01 -- ENGLISH – Printed on 13/03/00 as 01_PRep
GB
Connecting the AC adaptor
There are two jacks for AC adaptors. The AC adaptor supplied with the
Multi Media Port Replicator fits into the square jack. However, you can also
use other models of Toshiba AC adaptors that fit the round jack. A plastic
cover conceals one jack or the other.
Do not connect two AC adaptors to the Multi Media Port Replicator at the
same time.
Do not connect an AC adaptor to the Multi Media Port Replicator and
computer at the same time. Connect the AC adaptor to the Multi Media
Port Replicator only.
Connecting the AC adaptor
(model supplied with the Multi Media Port Replicator)
Connecting the AC adaptor (model not supplied)
If you do not connect an AC adaptor, the PC card slot and USB port will
not operate. All other ports and jacks can be used without connecting an
AC adaptor.
